- Page 1 Rod locking EN Additional installation instructions for the product families Slimdrive SL Slimdrive SLT Slimdrive SC 136395-03...
-
Page 2: Table Of Contents
Intended use ................................3 Overview..................................3 Diagrams ..........................................3 Tools and aids ........................................4 Assembly of Slimdrive SL and Slimdrive SLT product families (without RC2 variants) ....4 Pre-conditions ........................................4 Mounting the locking device ..................................5 Aligning the locking device ..................................6 Assembly of RC2 variants of the Slimdrive SL product family ..............7 Pre-conditions ........................................7... -
Page 3: Introduction
GEZE GmbH is referred to as GEZE below. The respective intended use for the sliding door system applies. Any other use is considered non-intended and will lead to the exclusion of all liability and warranty claims to GEZE. Overview 3. 1 Diagrams Drawing no. -
Page 4: Tools And Aids
Assembly of Slimdrive SL and Slimdrive SLT product families (without RC2 variants) Rod locking Tools and aids Tool Closer size Tape measure Marking pen Torque spanner Allen key 1.5 mm–6 mm Open-ended spanner 8 mm, 10 mm, 13 mm, 15 mm Side-cutting pliers... -
Page 5: Mounting The Locking Device
Rod locking Assembly of Slimdrive SL and Slimdrive SLT product families (without RC2 variants) Dimension “X”: à Slimdrive SL product family: X = 53 mm (shown) à Slimdrive SLT product family: X = 105.5 mm "X" Mounting the locking device The position of the dead bolt (1) can be changed by turning the manual unlocking (4) with an Allen key (6 mm) (see Emergency operation, Chapter 11). -
Page 6: Aligning The Locking Device
Assembly of Slimdrive SL and Slimdrive SLT product families (without RC2 variants) Rod locking Tighten the fixing screws (7) of the housing fasteners so that the locking device can be moved in the track with as little play as possible. -
Page 7: Assembly Of Rc2 Variants Of The Slimdrive Sl Product Family
Risk of injury due to glass breakage. Always mount the door leaf together with another person. The base structures (11) are available as an option (support bracket, base plate). See the installation diagrams for the RC2 variants of Slimdrive SL and Slimdrive SLT. 53 mm... - Page 8 Assembly of RC2 variants of the Slimdrive SL product family Rod locking Remove roller carriage from transport locking device. Unscrew the suspension bolt (16) from the roller carriage. Unscrew the lock nut (17) from the hanger bolt (16). Slide the move lock (14) onto the door suspension (15).
- Page 9 Rod locking Assembly of RC2 variants of the Slimdrive SL product family WARNING! Risk of crushing! The door leaves are still unsecured and move easily. Make sure that the door leaves are not moved accidentally or by unauthorised persons. Screw the door leaf (18) to the door suspension using 2 screws (19) each.
- Page 10 Assembly of RC2 variants of the Slimdrive SL product family Rod locking 5.2.2 Adjusting the door leaves Observe the applicable standards and guidelines on crushing, shearing and drawing-in spots. Align door leaves flush with each other. Ensure the same level and parallel closing edges when doing so.
-
Page 11: Adjusting The Locking Device
Rod locking Assembly of RC2 variants of the Slimdrive SL product family Adjusting the locking device Move the door leaves into the closing position. Loosen the screws (21) and (22). 2-leaf 1-leaf, left hand slide to open Position the locking device over the door leaves so that the dead bolt can travel into the main closing edge profiles in a non-contact manner. -
Page 12: Mounting The Bottom Plate
Assembly of RC2 variants of the Slimdrive SL product family Rod locking Mounting the bottom plate 2-leaf 1-leaf, left hand slide to open Drill 3 threaded holes (26) at the marked positions. Screw the bottom plate (23) to the substructure using 3 countersunk screws (25) (7 Nm± 0.5 Nm). - Page 13 Rod locking Assembly of RC2 variants of the Slimdrive SL product family Drill 3 threaded holes (29) for the reinforcement bracket (28) at the left- and right-hand side secondary closing edge in the substructure (optional). Screw the reinforcement bracket (28) to the substructure (optional) using 3 countersunk screws (27)(7 Nm ± 0.5 Nm).
-
Page 14: Installing Stop Buffers
Assembly of RC2 variants of the Slimdrive SL product family Rod locking Installing stop buffers Move the door leaves into the open position. Loosen the screw (32) sufficiently so that the stop buffer (30) with the clamping plate (31) can be introduced into the track. -
Page 15: Assembly Of Rc2 Variants Of The Slimdrive Sc Product Family
Rod locking Assembly of RC2 variants of the Slimdrive SC product family Assembly of RC2 variants of the Slimdrive SC product family 6. 1 Pre-conditions à Slimdrive is set up completely à Door leaves are hung in and are oriented parallel to each other à... -
Page 16: Making The Holes For The Locking Bolts
Assembly of RC2 variants of the Slimdrive SC product family Rod locking In the closed position of the moving leaves use the manual unlocking (4) to move the rod locking downwards so that the impressions of the locking bolts can be seen on the tape (2). Making the holes for the locking bolts Turn the manual unlocking back again and slide the door leaves to the open position. -
Page 17: Aligning The Height Of The Top And Bottom Parts Of The Locking Bolt
Rod locking Aligning the height of the top and bottom parts of the locking bolt Aligning the height of the top and bottom parts of the locking bolt Requirement à Door leaves not connected with the toothed belt! Pull the rubber door sealing profile (33) at the top and bottom out of the side strip until the outer lower (35) or upper hole (34) can be accessed. -
Page 18: Adjusting The Switching Points
Adjusting the switching points Rod locking Adjusting the switching points Adjusting of the switching points is used to specify the respective end points of the locking bolts (locked/unlocked). In order to avoid system faults ensure that the switching points are set with great care. If set incorrectly, the switch contacts are not actuated in the end positions of the locking mechanism. -
Page 19: Emergency Operation
Rod locking Emergency operation Emergency operation The manual unlocking can be used to lock or unlock the rod locking manually in emergencies. Insert the Allen key (6 mm) through the hole in the cover next to the locking mechanism. The hole is identified by a label. By turning the Allen key in the specified directions the door is manually à... - Page 20 E-Mail: leonberg.de@geze.com Baltic States – Iberia Scandinavia – Norway Lithuania / Latvia / Estonia GEZE Iberia S.R.L. GEZE Scandinavia AB avd. Norge GEZE GmbH E-Mail: norge.se@geze.com E-Mail: baltic-states@geze.com E-Mail: info.es@geze.com Niederlassung Süd-Ost www.geze.no www.geze.es Tel. +49 (0) 7152 203 6440 E-Mail: muenchen.de@geze.com...
