SmartAire
MZ Basic
STEP 4: CONNECT THE SENSOR TO THE TREE
Connect temperature sensor #1 to the temperature tree.
Connect Sensor #1
Split Connector
RGB LED Indicator and Sensor #1
Note that SmartAire Basic will only be provided with Sensor 1 and does not require sensors 2-4 to operate.
STEP 5: CONNECT THE LED INDICATOR
