STEP 9: DEPLOY THE AIR BLOCKERS

Slightly loosen the "air blockers" from the frame and slide them to the fully extended position. Then
Retighten the screws down to lock them in position.
A MANUAL PHILIPS HEAD SCREWDRIVER OR A TORQUE LIMITING ELECTRIC
SCREW DRIVER IS BEST FOR THIS PORTION OF THE INSTALLATION TO AVOID
OVER-TORQUING DAMAGE USE OF MORE THAN 15 IN.LB TORQUE MAY DAMAGE
FASTENER.
UN TOURNEVIS CRUCIFORME OU UN TOURNEVISE ELECTRIC AVEC UN LIMITEUR
DE COUPLE EST PRÉFÉRABLE POUR CETTE PARTIE DE L'INSTALLATION POUR ÉVITE
UN SERRAGE EXCESSIF. PLUS QUE 15 IN.LB DE COUPLE PEUT ENDOMMAGER LA
VISE
