User Installation Manual
®
SmartAire
MZ Basic
INITIAL SETUP
STEP 1: PREPARE THE JOB SITE
Mounting hardware not included in SmartAire MZ kit. These must be ordered separately.
Please ensure the installment site is clean and free of obstructions.
Unpack unit and all accessories. Prepare zip ties and associated mounting hardware available nearby.
Prepare the DirectAire® or DirectAire® Al Panel and Installation Location.
HANDLE UNIT WITH CARE, DO NOT MANUALLY ADJUST DAMPER BLADES,
SUPPORT OR LIFT UNIT BY DAMPER BLADES.
MANIPULER L'UNITÉ AVEC SOIN, NE PAS AJUSTER LES LAMES DU REGISTRE
MAUNELLEMENT, NE PAS SOUTENIR OU LEVER L'UNITÉ PAR LES LAMES.
7510 Montevideo Road
r1.0-12/11/15
© 2015 Tate Access Floors, Inc.
Jessup, MD 20794
SmartAire_mzb_Installation.docx
Tel (410)799-4200
7 of 27
