Tate SmartAire MZ Basic User & Installation Manual page 22

T4SetPointOverride Manual Set Point override on zone
4; Ignored with value of 0
T1_Fail
1: Power Alarm
2: High
Temperature Alarm
Zone Failure
3: Servo Failure
Alarm
4: Temperature
Sensor Failure
T2_Fail Zone Failure
T3_Fail Zone Failure
T4_Fail Zone Failure
Temp in deg F
0:deg C
1:deg F
0: off
Board OFF/ON
1: on
Zone 1 0: Disable
Disable/Enable 1: Enable
Zone 2 0: Disable
Disable/Enable 1: Enable
Zone 3 0: Disable
Disable/Enable 1: Enable
Zone 4 0: Disable
Disable/Enable 1: Enable
High Temperature Threshold for
LED_Hi
LED Indicator
High Temperature Warning
LED_HiWarn
Threshold for LED indicator
Low Temperature Warning
LED_LoWarn
Threshold for LED indicator
Low Temperature Threshold for
LED_Lo
LED indicator
LED_Mode
0: Solid Colors LED Color Mode
1: Rainbow
Custom Red (High Temperature)
Custom_RED
Color
Custom Green (Normal
Custom_GRN
Temperature) Color
Custom Blue (Low Temperature)
Custom_BLU
Color
7510 Montevideo Road
Jessup, MD 20794
Tel (410)799-4200
User Installation Manual
Deg F
Deg F
Deg F
Deg F
Deg F
r1.0-12/11/15
SmartAire_mzb_Installation.docx
0.0 32.0 122.0
0 0 4
0 0 4
0 0 4
0 0 4
0 0 1
1 0 1
1 0 1
1 0 1
1 0 1
81 32 122
79 32 122
73 32 122
71 0 122
0 0 1
#FF00 #00000 #FFFF
00 0 FF
#00FF #00000 #FFFF
00 0 FF
#0000 #00000 #FFFF
FF 0 FF
© 2015 Tate Access Floors, Inc.
®
SmartAire MZ Basic
Zone Failures are
indicators of issues on
the unit. The SmartAire
will also create an
audible alarm if any of
these conditions have
caused failure.
Adjust whether the unit
operates in Fahrenheit
or Celsius Units.
This value turns on and
off the unit.
These values are
managed for
individually disabling
zones on the
SmartAire.
Solid colors will force
unit to change at given
set points above from
Blue (below 71) to
blinking Blue-Green
(71-73) and continue to
solid red (above 81).
Rainbow mode will
slowly transition
through the colors as
the temperature varies.
User can adjust color
set points or set LED to
a custom color by
changing all three
variables to single value
22 of 27
