Seamless Switch Function：
Press button 1 – 4: the video output will be a single full screen, and the button
light goes ON to indicate the source of video input.
Multi-view Switch Function：
Press button 5 – 9: the video output will be a multi-view window; the button light
goes ON to indicate the Multiview mode.
SWITCHER Function：
SWITCHER has video auto switching function, you could select two or four videos
to automatically display, with the switching time duration set as indicated below:
Press SWITCHER button: (the button light goes ON) then press button 1 – 4 to select the
video for auto switching.
Press button 5 – 9 to select the auto switching timing :
5 : 5 seconds
6 : 10 seconds
7 : 20 seconds
8 : 30 seconds
9 : 60 seconds
Press the SWITCHER button again to leave switching mode.
AUDIO Function：
When in Multiview display mode, only one audio input can be selected:
Press AUDIO button (the button light goes ON), then press button 1 – 4 to select the
audio source. Press the AUDIO button again to leave audio selection mode.
SCENE Function：
The SCENE button for the scene function. There are 9 sets of saved scene modes for
easy save and load.
SCENE Saved method:
Press SCENE button for 3 seconds until button light flash, then press button 1- 9 to
save. Press SCENE button again to exit.
3
