NTI SPLITMUX Series Installation And Operation Manual page 2

The HDMI Quad Multi-viewer allows you to display HDMI video signals from 4 different sources
onto one HDTV. It supports Quad/POP/full screen with 6 modes and a special feature built-in
auto-switching function between 4 different sources. It is easy to operate with great features for
viewing or monitoring multiple videos on one screen at the same time from video devices such as
computer, Blu-ray player, cable box, DVR, surveillance camera, etc. Perfect to use in surveillance,
advertising, education, industry and commercial applications, private Home Theatres etc.
Features:
Multiplexes 4 HDMI inputs into 1 HDMI output.

Supports resolutions up to 1080p 60Hz.

Supports scaler up to 1080p functions and digital audio format LPCM 2.0.

Control option: IR remote control, front panel buttons.

Supports Quad, multi-view and seamless switching.

Supports auto switching between 4 sources.

HDM 1.3a, HDCP 1.2 ,DVI 1.0 complaint.

Supports different display modes: Quad, picture on picture (POP) and full screen.

Perfect for controlling remote machines and security monitoring systems, digital

signage applications.
1
