Panel View - NTI SPLITMUX Series Installation And Operation Manual

Low-cost hdmi quad screen splitter/multiviewer

Hide thumbs Also See for SPLITMUX Series:

Table of Contents

Panel View:

Panel Button Function:

Button

Select Video 1

Select Video 2

Select Video 3

Select Video 4

Quad Picture Display

Quad Picture Display (one big window with three small windows),

press this button again to change 4 video sequence.

Select 3 Video Display (Only select input video 1,2,3)

Select 2 Video Display, press this button again to select video input 1,2

or 3,4.

Select 4 Video Display

Auto Switching

Audio Selection

Scene Selection

Function
