RS-232 SERIAL CONSOLE PORT
The following table lists the pin configuration for the RS-232 3-pin Mini Jack
mating connector for the console serial port.
Pin
DB9-F Pin#
Tip
Ring
Sleeve
Tip
Signal Name
2
Transmit
3
Receive
5
Return
Sleeve
Ring
IE-iMcV-T1-Mux/4+Ethernet
27
Direction
Out of Unit
In to Unit
Return
