EKI-3525M/3525S
Industrial Unmanaged Fiber Optic Ethernet Switch

Overview

The EKI-3525M/S are a new generation of products
and have four 10/100 Mbps Ethernet ports, and one
multi-mode or single-mode fiber-optic port. Using
fiber-optics, you can prevent noise from interfering
with your system and support high-speed (100 Mbps)
and high-distance (up to 30 km) transmissions. A low
power Ethernet design automatically adjusts power
consumption by detecting the link status and cable
length. Designed with one "VIP" port to get optimal
bandwidth for media traffic through the VIP port
users can experience better multimedia streaming
performance through the prioritized bandwidth set-
ting. The devices come with compact metal and plas-
tic housing that is IP40 rated to protect against dusty
industrial environments. The wide power input
power (8.4 to 52. VDC) is dedicated to operating in
8
areas of unstable power and rugged environments. It
also provides an event alarm and in the event of a
power failure and connection loop, the integrated
LED will activate the alarm to notify administrators.

Packing List

Before installation, please make sure that you have
received the following:
• 1 x EKI-3525M or EKI-3525S Industrial Unman-
aged Fast Ethernet Switch
• 1 x Wall mounting bracket
• 1 x DIN-rail Mounting Bracket and Screws
• 1 x EKI-3525M or 3525S startup manual
If anything is missing or damaged, contact your
distributor or sales representative immediately.
Notes
For more information on this and other Advantech
products, please visit our websites at:
http://www.advantech.com/eAutomation
For technical support and service:
http://www.advantech.com/support/
1
Startup Manual

Specifications

General
• Compatibility: IEEE 802.3, 802.3u, 802.3x,
• LAN: 10/100Base-TX
• Ethernet RJ-45: Up to 100 m
• Optical Fiber
• Connectors: 4 x RJ45 ports + 1 x SC type fiber
• Switch Architecture: Store and Forward
• Power Requirement: 12~48V
• Power Consumption:1.5 Watts
• Dimensions (W x H x D): 27x120x85 mm
• Enclosure: IP40
• Operating Temperature: -10 ~ 60°C
• Storage Temperature: -40 ~ 85°C (-40°F~185°F)
• Operating/Storage Humidity: 5%~95%
• Safety: UL60950
• EMC: FCC Class A, CE
• Warranty: 5 years
1st Edition
November 2013
802.3az, 802.1P
Multi-Mode (EKI-3525M)
Wavelength:1310nm
Tx Power: -14/-20 dBm
Rx Sensitivity: -31 dBm
Parameters: 50/125 um, 62.5/125 um
Single-Mode (EKI-3525S)
Wavelength: 1310 nm
Tx Power: -8/-15 dBm
Rx Sensitivity: -34 dBm
Parameters: 9/125 um
connector
6-pin removable screw terminal (Power &
Relay)
Power Input with reverse polarity protection.
(14°F~140°F)
(noncondensing)
, Redundant
DC
