2.2.21 DC IN (DC IN 1 x 4 pin power connector)
21
DC IN power connector
41
www.gigaipc.com
Pin 1
Pin No.
GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Definition
1
GND
2
DCIN
3
DCIN
4
GND
