Page 1: Sbc Boards
QBiP-1165G7B/ QBiP-1135G7B/ QBiP-1115G4EB 3.5” SBC Boards User’s Manual 1st Ed www.gigaipc.com... -
Page 2: Copyright Notice
While reasonable efforts have been made in the preparation of this document to assure its accuracy, GIGAIPC assumes no liabilities resulting from errors or omissions in this document, or from the use of the information contained herein. -
Page 3: Acknowledgement
Core, Atom are trademarks of Intel Corporation • • ITE is a trademark of Integrated Technology Express, Inc. IBM, PC/AT, PS/2, and VGA are trademarks of International Business • Machines Corporation. All other product names or trademarks are properties of their respective owners. www.gigaipc.com... -
Page 4: Packing List
Before setting up your product, please make sure the following items have been shipped: Item Quantity QBiP-1165G7B/ QBiP-1135G7B / QBiP-1115G4EB MB SATA power cable If any of these items are missing or damaged, please contact your distributor or sales representative immediately. -
Page 5: About This Document
(if any), its specifications, dimensions, jumper/ connector settings/definitions, and driver installation instructions (if any), to facilitate users in setting up their product. Users may refer to the GIGAIPC.com for the latest version of this document. www.gigaipc.com... -
Page 6: Safety Precautions
Make sure the device is installed near a power outlet and is easily accessible. 10. Keep this device away from humidity. 11. Place the device on a solid surface during installation to prevent falls 12. Do not cover the openings on the device to ensure optimal heat dissipation. www.gigaipc.com... - Page 7 18. D O N O T L E AV E T H I S D E V I C E I N A N U N C O N T R O L L E D ENVIRONMENT WITH TEMPERATURES BEYOND THE DEVICE’S PERMITTED STORAGE TEMPERATURES (SEE CHAPTER 1) TO PREVENT DAMAGE. www.gigaipc.com...
-
Page 8: Fcc Statement
Il y a un risque d’explosion si la batterie est remplacée de façon incorrecte. Ne la remplacer qu’avec le même modèle ou équivalent recommandé par le constructeur. Recycler les batteries usées en accord avec les instructions du fabricant et les directives gouvernementales de recyclage. www.gigaipc.com... -
Page 9: China Rohs Requirements (Cn)
China RoHS Requirements (CN) 产品中有毒有害物质或元素名称及含量 GIGAIPC Main Board/ Daughter Board/ Backplane 有毒有害物质或元素 部件名称 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) 印刷电路板 及其电 ○ ○ ○ ○ ○ ○ 子组件 外部信号 连接器 ○ ○ ○ ○... -
Page 10: China Rohs Requirement (En)
China RoHS Requirement (EN) Poisonous or Hazardous Substances or Elements in Products GIGAIPC Main Board/ Daughter Board/ Backplane Poisonous or Hazardous Substances or Elements Component Hexavalent Polybrominated Polybrominated Lead Mercury Cadmium Chromium Biphenyls Diphenyl Ethers (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) PCB &... -
Page 11: Table Of Contents
AT_CN (AT/ATX power mode select jumper) ....24 2.2.5 JCOM1 (COM1 RI# pin RI#/5V/12V Select) ....25 2.2.6 SATA0 (SATA 6Gb/s connector) ........26 2.2.7 SATAPW0 (SATA 6Gb/s power connector) ....27 2.2.8 COM2, COM3, COM4 (Serial port header, ....28 RS-232/422/485) ............28 www.gigaipc.com... - Page 12 2.2.19 BKL_CN (Back light brightness control header) .... 38 2.2.20 LVDS (LVDS connector) ..........39 2.2.21 LSW (LVDS resolution jumper) ........40 2.2.22 M2M (M.2 Slot, SATA/PCIeX2, NGFF 2280) ....41 2.2.23 SODIMM1, SODIMM2 (DDR4 SO-DIMM Slot) ....41 2.2.24 TPM (Trusted Platform Module Connector) ....42 www.gigaipc.com...
-
Page 13: Chapter 1 - Product Specifications
Chapter 1 Chapter 1 - Product Specifications www.gigaipc.com... - Page 14 www.gigaipc.com...
-
Page 15: Specifications
Specifications QBiP-1165G7B QBiP-1135G7B QBiP-1115G4EB Motherboard 3.5’’ SBC Form Factor 146W x 101.7Dmm Intel® Core™ i7- Intel® Core™ i5- Intel® Core™ i3- 1165G7 Processor 1135G7 Processor 1115G4E Processor 10nm SuperFin, 10nm SuperFin, 10nm SuperFin, 4 cores, 8 threads, 4 cores, 8 threads, 2 cores, 4 threads, up to 4.7 GHz,... - Page 16 QBiP-1165G7B QBiP-1135G7B QBiP-1115G4EB Motherboard 1 x 2280 M.2 M-Key (PCIe x2, SATA 6Gb/s) 1 x 2230 M.2 E-Key Expansion Slots 1 x Full-size mini PCIe with SIM slot 1x PCIe x1 (Board to Wire connector, PCIe Gen3 x 1) 1 x 4 pin box power connector (DC in +9V ~ 48VDC)
-
Page 17: Chapter 2 - Hardware Information
Chapter 2 Chapter 2 – Hardware Information www.gigaipc.com... -
Page 18: Jumpers And Connectors
Jumpers and Connectors www.gigaipc.com... - Page 19 General purpose input / ouput header FP_AUDIO Front Audio connector PCIEX1 PCIe Gen3 x1 connector ME Enable jumper SPK_OUT Speaker out connector BKL_CN Back light brightness control header LVDS LVDS connector LVDS resolution jumper M.2 Slot, SATA/PCIex2, NGFF 2280 www.gigaipc.com...
- Page 20 Code Description SODIMM1 DDR4 SO-DIMM Slot SODIMM2 Trusted Platform Module connector USB31_1 USB3.2 Gen2x1 connector USB31_2 HDMI_21 HDMI connector LAN1, LAN2 LAN connector COM1 Serial port www.gigaipc.com...
-
Page 21: Sys_Fan (System Fan Connector)
2.2.1 SYS_FAN (System fan connector) Pin 1 System fan Connector Connector PN Vendor 85205-0470N ACES A1250WV-S-04PC JOINT-TECH Pin No. Definition Detect Speed control www.gigaipc.com... -
Page 22: Cpu_Fan (Cpu Fan Connector)
2.2.2 CPU_FAN (CPU fan connector) Pin 1 CPU fan Connector Connector PN Vendor 85205-0470N ACES A1250WV-S-04PC JOINT-TECH Pin No. Definition Detect Speed control www.gigaipc.com... -
Page 23: Fusb1, Fusb2 (Usb2.0 Headers)
2.2.3 FUSB1, FUSB2 (USB2.0 headers) Pin 1 USB 2.0 Header Connector PN Vendor 210-92-05GB04 PINREX PH10R53BAZ009 HORNGTONG Pin No. Definition No Pin No Connect www.gigaipc.com... -
Page 24: At_Cn (At/Atx Power Mode Select Jumper)
AT_CN (AT/ATX power mode select jumper) Pin 1 AT/ATX power mode select jumper Connector PN Vendor 220-96-03GB01 PINREX HORNGTONG PH03N2 7BAN000 Pin No. Definition AT MODE TXD5 ATX MODE Jumper setting 1-2 Close : AT mode. 2-3 Close : ATX mode.(Default setting) www.gigaipc.com... -
Page 25: Jcom1 (Com1 Ri# Pin Ri#/5V/12V Select)
2.2.5 JCOM1 (COM1 RI# pin RI#/5V/12V Select) Pin 1 JCOM1 Jumper Select Connector PN Vendor 220-97-03GB01 PINREX 1-2 Close: 5V (Power COM) PH06N53BAZ000 HORNGTONG 3-4 Close: RI (Stand COM) (Default-Setting) 5-6 Close: 12V (Power COM) www.gigaipc.com... -
Page 26: Sata0 (Sata 6Gb/S Connector)
2.2.6 SATA0 (SATA 6Gb/s connector) SATA Connector Connector PN Vendor WATF-07DBLBA1UW WINWIN Pin No. Definition www.gigaipc.com... -
Page 27: Satapw0 (Sata 6Gb/S Power Connector)
2.2.7 SATAPW0 (SATA 6Gb/s power connector) Pin 1 Hard Disk Power Connector Connector PN Vendor 743-81-04TW00 PINREX WF04Q2-3BJQ000 HORNGTONG Pin No. Definition www.gigaipc.com... -
Page 28: Com2, Com3, Com4
2.2.8 COM2, COM3, COM4 (Serial port header, RS-232/422/485) Pin 1 Serial Port Cable Connector Connector PN Vendor 725-81-10TW00 PINREX A2004WV-2X05P46 JOINT-TECH Definition Pin Definition No Connect RI/ 5V/ 12V www.gigaipc.com... -
Page 29: M2E (M.2 Slot, E-Key, Ngff2230, Wifi & Bluetooth Module)
2.2.9 M2E (M.2 Slot, E-key, NGFF2230, WiFi & Bluetooth module) 2.2.10 MPCIE (Mini PCIe full size, support 3G/4G module) www.gigaipc.com... -
Page 30: Battery (Battery Cable Connector)
2.2.11 BATTERY (Battery cable Connector) Pin 1 Battery cable Connector Connector PN Vendor 85205-0270L ACES A1250WV-S-02PC JOINT-TECH Pin No. Definition 3.3V www.gigaipc.com... -
Page 31: Dc_In (Dc In 1X4 Pin Power Connector)
2.2.12 DC_IN (DC IN 1x4 pin power connector) Pin 1 DC IN connector Connector PN Vendor 753-81-04TW00 PINREX 1 2 34 Pin No. Definition Power Power www.gigaipc.com... -
Page 32: Sys_Panel (Front Panel Header)
2.2.13 SYS_PANEL (Front panel header) Pin 1 System Panel Header Connector PN Vendor 210-92-05G111 PINREX Pin No. Definition HDD LED+ Power LED+ HDD LED- Power LED- Power Button+ Reset Button Power Button- No Connect No Pin www.gigaipc.com... -
Page 33: Gpio_Cnt (General Purpose Input/Output Header)
2.2.14 GPIO_CNT (General Purpose input/output header) Pin 1 GPIO Connector Pin No. Definition SMB_DATA Connector PN Vendor Pin No. Definition 725-81-12TW00 PINREX GPO1 A2004WV-2X06P46 JOINT-TECH GPI1 GPO2 GPI2 GPO3 GPI3 GPO4 GPI4 SMB_CLK www.gigaipc.com... -
Page 34: Fp_Audio (Front Audio Connector)
2.2.15 FP_AUDIO (Front Audio connector) Pin 1 Front Audio Connector Connector PN Vendor 725-81-10TW00 PINREX A2004WV-2X05P46 JOINT-TECH Definition Pin Definition MIC_L MIC_JD FAUDIO_JD MIC_R No Connect Detect HPOUT_L HPOUT_R www.gigaipc.com... -
Page 35: Pciex1 (Pcie Gen3 X1 Connector)
2.2.16 PCIEX1 (PCIe Gen3 x1 connector) Pin 1 PCIe Gen3 x1 Connector Connector PN Vendor 115B20-100020-G4-R STARCONN Pin No. Definition Pin No. Definition SRC_DP SMDATA SRC_DN CLK_REQ# PLTRST# PEWAKE# SLP_S3# +V12A +V12A SMCLK +V12A www.gigaipc.com... -
Page 36: Me (Me Enable Jumper)
2.2.17 ME (ME Enable jumper) ME Enable Connector Connector PN Vendor 220-96-02GB01 PINREX ME Enable jumper Default Enable www.gigaipc.com... -
Page 37: Spk_Out (Speaker Out Connector)
2.2.18 SPK_OUT (Speaker out connector) Pin 1 Audio Amplifie Connector Connector PN Vendor 721-81-045W00 PINREX A2001WV-04P146 JOINT-TECH Pin No. Definition Speaker Out L+ Speaker Out L- Speaker Out R- Speaker Out R+ www.gigaipc.com... -
Page 38: Bkl_Cn (Back Light Brightness Control Header)
2.2.19 BKL_CN (Back light brightness control header) Pin 1 Back light brightness control Connector PN Vendor connector 721-81-05TW00 PINREX A2001WV-05P146 JOINT-TECH Pin No. Definition Back Light Enable www.gigaipc.com... -
Page 39: Lvds (Lvds Connector)
But below model no need to add. A0~A3 is odd channel 0~3, A4~A7 is even channel. Note: *The LVDS output connector of the unit is only intended to be connected to an UL/IEC/EN CLK2+ approval equipment with fire enclosure. CLK1+ CLK2- www.gigaipc.com... -
Page 40: Lsw (Lvds Resolution Jumper)
1024 x 600 1600 x 900 18bit 24bit 1280 x 800 1680 x 1050 18bit 24bit 1024 x 600 1600 x 1200 18bit 24bit 1280 x 1024 1920 x 1080 24bit 24bit 1366 x 768 1920 x 1200 18bit 24bit www.gigaipc.com... -
Page 41: M2M (M.2 Slot, Sata/Pciex2, Ngff 2280)
2.2.22 M2M (M.2 Slot, SATA/PCIeX2, NGFF 2280) 2.2.23 SODIMM1, SODIMM2 (DDR4 SO-DIMM Slot) www.gigaipc.com... -
Page 42: Tpm (Trusted Platform Module Connector)
2.2.24 TPM (Trusted Platform Module Connector) Pin 1 TPM Module Connector Connector PN Vendor 87216-1004-06 ACES Pin No. Definition SPI_CS#2 TPM_SO TPM_RST# TPM_SI TPM_CLK +V3.3A www.gigaipc.com...
