QBiP-2718A

3.5" SBC Boards- QBiP-2718A

User's Manual 1st Ed
1
www.gigaipc.com
GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the QBiP-2718A and is the answer not in the manual?

Questions and answers

Related Manuals for GIGAIPC QBiP-2718A

Summary of Contents for GIGAIPC QBiP-2718A

  • Page 1: Sbc Boards- Qbip-2718A

    QBiP-2718A 3.5” SBC Boards- QBiP-2718A User’s Manual 1st Ed www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 2: Copyright Notice

    GIGAIPC reserves the right to make changes in the product design without notice to its users. www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 3: Acknowledgement

    IBM, PC/AT, PS/2, and VGA are trademarks of International Business • Machines Corporation. All other product names or trademarks are properties of their respective owners. www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 4: Packing List

    Item Quantity QBiP-2718A SATA power cable If any of these items are missing or damaged, please contact your distributor or sales representative immediately. www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 5: About This Document

    (if any), to facilitate users in setting up their product. Users may refer to the GIGAIPC.com for the latest version of this document. www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 6: Safety Precautions

    11. Place the device on a solid surface during installation to prevent falls 12. Do not cover the openings on the device to ensure optimal heat dissipation. www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 7 18. D O N O T L E AV E T H I S D E V I C E I N A N U N C O N T R O L L E D ENVIRONMENT WITH TEMPERATURES BEYOND THE DEVICE’S PERMITTED STORAGE TEMPERATURES (SEE CHAPTER 1) TO PREVENT DAMAGE. www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 8: Fcc Statement

    Ne la remplacer qu’avec le même modèle ou équivalent recommandé par le constructeur. Recycler les batteries usées en accord avec les instructions du fabricant et les directives gouvernementales de recyclage. www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 9: China Rohs Requirements (Cn)

    ○ 及其电子组件 外部信号 ○ ○ ○ ○ ○ ○ 连接器及线材 O： 表示该有毒有害物质在该部件所有均质材料中的含量均在 SJ/T 11363-2006 标准规定的限量要求以下。 X： 表示该有毒有害物质至少在该部件的 某一均质材料中的含量超出 SJ/T 11363-2006 标准规定的限量要求。 备注： 此产品所标示之环保使用期限， 系指在一般正常使用状况下。 www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 10: China Rohs Requirement (En)

    SJ/T 11363-2006-stipulated requirement. Note: The Environment Friendly Use Period as labeled on this product is applicable under normal usage only www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 11: Table Of Contents

    SODIMM1, SODIMM2 (DDR4 SO-DIMM slot) ....26 2.2.6 SATA (SATA 6Gb/s connector) ........27 2.2.7 SATAPW (SATA power connector) ........28 2.2.8 FUSB (USB 2.0 header) ............. 29 www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 12 IT8786 Super IO Configuration ........49 3.3.3 Hardware Monitor ............50 3.3.4 S5 RTC Wake Settings ............51 3.3.5 CPU Configuration ............52 3.3.6 SATA Configuration ............53 www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 13 3.3.10 AMD CBS ................57 3.3.11 Digital IO Port Configuration ........... 58 Chipset ................59 Security ................60 Boot .................. 63 Save & Exit ............... 64 www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 14: Chapter1 - Product Specifications

    Chapter 1 Chapter1 - Product Specifications QBiP-2718A www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 15 101.7 95.2 www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 16: Specifications- Qbip-2718A

    3 x COM headers (RS-232/422/485) 1 x COM headers (RS-232/422/485 & RI/5V/12V) 1 x AT/ATX mode select jumper 1 x GPIO (8-bits) & SMBUS header www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 17 OS Compatibility Windows 10 (x64) Operating temperature: 0°C to 60°C Operating humidity: 0-90% (non-condensing) Operating Properties Non-operating temperature: -40°C to 85°C Non-operating humidity: 0%-95% (non-condensing) www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 18: Chapter 2 - Hardware Information

    Chapter 2 Chapter 2 – Hardware Information www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 19: Jumpers And Connectors

    Jumpers and Connectors www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 20 COM3, COM4 COM4 : RS-232/422/485 & RI/5V/12V Speaker out connector SPKR Front panel audio header FP_AUDIO M.2 E-key, NGFF 2230 MPCIE Mini PCIE slot www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 21 Code Description BATTERY Battery connector M.2 M-key, NGFF 2280 CPU_FAN CPU Fan connector LPC TPM header www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 22: Lan1, Lan2 (Lan Connector)

    1Gbps data rate Green On 100Mbps data rate 10Mbps data rate Pin No. Definition Pin No. Definition TX1+ TX3+ TX1- TX3- TX2+ TX4+ TX2- TX4- www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 23: Hdmi_43, Hdmi_21 (Hdmi Connector)

    DDC Clock DDC Clock TX1p TX1p DDC Data DDC Data TX1n TX1n TX0p TX0p Hot Plug Hot Plug Detect Detect TX0n TX0n CLKp CLKp www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 24: Usb31 (Usb 3.2 Gen 2X1 Connector)

    USB31 (USB 3.2 Gen 2x1 Connector) USB 3.2 Gen 2x1 connector Pin No. Definition Pin No. Definition USB3_RX1n USB3_RX2n USB3_RX1p USB3_RX2p USB3_TX1n USB3_TX2n USB3_TX1p USB3_TX2p www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 25: Usb2 (Usb 2.0 Connector)

    2.2.4 USB2 (USB 2.0 Connector) USB 2.0 connector Pin No. Definition www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 26: Sodimm1, Sodimm2 (Ddr4 So-Dimm Slot)

    2.2.5 SODIMM1, SODIMM2 (DDR4 SO-DIMM slot) www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 27: Sata (Sata 6Gb/S Connector)

    2.2.6 SATA (SATA 6Gb/s connector) Pin 1 SATA 6Gb/s Connector Pin No. Definition www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 28: Satapw (Sata Power Connector)

    2.2.7 SATAPW (SATA power connector) Pin 1 Hard Disk Power Connector Connector PN Vendor 743-81-04TW00 PINREX WF04Q2-3BJQ000 HORNGTONG Pin No. Definition www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 29: Fusb (Usb 2.0 Header)

    2.2.8 FUSB (USB 2.0 header) Pin 1 USB 2.0 header Connector PN Vendor 210-92-05GB04 PINREX PH10R53BAZ009 HORNGTONG Pin No. Definition No Pin No Connect www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 30: Sys_Panel (Front Panel Header)

    Vendor 210-92-05GW5W PINREX Pin No. Definition HDD LED+ Power LED+ HDD LED- Power LED- Power Button+ Reset Button Power Button- No Connect No Pin www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 31: Dc In (Dc In 1 X 4Pin Power Connector)

    2.2.10 DC IN (DC IN 1 x 4pin power connector) Pin 1 DC IN power connector Connector PN Vendor 753-81-04TW00 PINREX Pin No. Definition POWER IN POWER IN www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 32: At_Cn (At/Atx Mode Select Jumper)

    AT/ATX mode select jumper Pin No. Definition 1-2 Close : AT mode. AT mode 2-3 Close : ATX mode. Detect (Default setting) ATX mode www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 33: Gpio_Cnt (General Purpose Input/Output Header)

    GPIO Connector Connector PN Vendor 725-81-12TW00 PINREX A2004WV-2X06P46 JOINT-TECH Pin No. Definition GPIO-output_1 GPIO-input_1 GPIO-output_2 GPIO-input_2 GPIO-output_3 GPIO-input_3 GPIO-output_4 GPIO-input_4 SMBus Clock SMBus DATA www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 34: Jcom (Ri Pin Ri/5V/12V Select Jumper For Com4 Port)

    2.2.13 JCOM (RI pin RI/5V/12V Select jumper for COM4 port) Pin 1 JCOM Jumper Select 1-2 Close: 5V (Power COM) 3-4 Close: RI (Stand COM) Default 5-6 Close: 12V (Power COM) www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 35: Com1, Com2, Com3, Com4 (Serial Port Header)

    For RI/5V/12V jumper setting, please see P. 34 TXD- RXD- — RXD+ — — — — — — — — — No Connect — — RI/5V/12V — — www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 36: Spkr (Speaker Out Connector)

    Speaker out connector Connector PN Vendor 721-81-045W00 PINREX A2001WV-04P146 JOINT-TECH Pin No. Definition Speaker Out L+ Speaker Out L- Speaker Out R- Speaker Out R+ www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 37: Fp_Audio (Front Panel Audio Header)

    Pin 1 Front panel audio header Connector PN Vendor 725-81-10TW00 PINREX A2004WV-2X05P46 JOINT-TECH Definition Definition MIC-Left MIC-Right Detect HPOUT_ MIC_JD Right FAUDIO_JD HPOUT_Left 10 HPOUT_JD www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 38: M2E (M.2 E-Key, Ngff 2230)

    Pin No. Definition PCIE_WAKE BT_Disable# WLAN_ USB_Dp DISABLE USB_Dn Connector PN Vendor Pin No. Definition Pin No. Definition APCI0095-P002A LOTES 80152-8521 BELLWETHER WLAN_TXp WLAN_TXn www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 39: Mpcie (Mini Pcie Slot)

    PCIE_WAKE# 3.3V 1.5V 1.5V PCIE_ SIM_PWR CLKREQ# 3.3V SIM_DATA Connector PN Vendor PCIE_CLKn SIM_CLK PCIE_CLKp SIM_RST AS0B221-S99Q-7H FOXCONN SIM_VPP PCIE_DISABLE PCIRST# PCIE_RXn 3.3V PCIE_RXp www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 40: Battery (Battery Connector)

    2.2.19 Battery (Battery Connector) Pin 1 Battery Connector Pin No. Definition www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 41: M2M (M.2 M-Key, Ngff 2280)

    3.3V Pin No. Definition Pin No. Definition 3.3V 3.3V SUSCLK 3.3V M2_SSD_ 3.3V Detect 3.3V 3.3V Connector PN Vendor PCIE_RXn 2E0BC41-C85CM-LH FOXCONN PCIE_RXp PCIE_TXn www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 42: Cpu_Fan (Cpu Fan Connector)

    2.2.21 CPU_FAN (CPU FAN connector) Pin 1 CPU FAN connector Connector PN Vendor 85205-0470N ACES 4 3 2 1 A1250WV-S-04PC JOINT-TECH Pin No. Definition Detect Speed Control www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 43: Lpc Tpm Header)

    Pin 1 TPM header Pin No. Definition 3.3V SERIRQ Connector PN Vendor 87216-1004-06 ACES Pin No. Definition LPC_CLK LFRAME# LAD0 PCI_RST LAD1 LAD3 LAD2 www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.

  • Page 44: Chapter 3 - Bios

    Chapter 3 Chapter 3 – BIOS www.gigaipc.com...

  • Page 45: Introduction

    Execute command or enter the submenu Increase the numeric value or make ＋ changes Decrease the numeric value or make – changes General Help Previous Values Load Optimized Defaults Settings Save changes & Exit the BIOS Setup program Exit the BIOS Setup program www.gigaipc.com...

  • Page 46: The Main Menu

    Shows the total memory size of the installed memory Set the Date for the system System Date (Format : Week - Month - Day - Year) Set the time for the system System Time (Format : Hour - Minute - Second) www.gigaipc.com...

  • Page 47: Advanced

    Advanced The Advanced menu is to configure the functions of hardware settings through submenu. Use arrow keys to move among the items, and press <Enter> to access into the related submenu. www.gigaipc.com...

  • Page 48: Tpm Configuration

    Pending operation : Trusted Computing None : No execution will be conducted (Default setting) TPM clear : Set to clear data on TPM Physical Presence Spec Version : Choose PPI spec version Option items : 1.2 or 1.3 (Default setting) www.gigaipc.com...

  • Page 49: It8786 Super Io Configuration

    Disabled : if Disabled, displays no configuration for the serial port Configuration Device settings : Serial Port 3 Display the specified Serial Port base I/O address and IRQ Configuration Mode : Serial Port 4 Choose RS-232, RS-422, or RS-485 feature Configuration www.gigaipc.com...

  • Page 50: Hardware Monitor

    Normal : Fan speed set by BIOS default (Default setting) Control Full Speed : Set Fan operates at full speed CPU Temperature Shows current CPU temperature System Shows current system temperature Temperature CPU Fan Speed shows current CPU Fan speed www.gigaipc.com...

  • Page 51: S5 Rtc Wake Settings

    Enable or Disable System to wake on a specific time. Wake system Disabled : Disables system to wake on a specific time (Default setting) from S5 Fixed Time : Enables system to wake on a specific time (Format : hr : min : sec) www.gigaipc.com...

  • Page 52: Cpu Configuration

    Enabled : Enables NX Mode (Default setting) NX Mode Disabled : Disables NX Mode Enables or Disables the CPU virtualization funtion. Enabled : Enables SVM Mode (Default setting) SVM Mode Disabled : Disables SVM Mode Node 0 Information Shows AMD CPU information www.gigaipc.com...

  • Page 53: Sata Configuration

    3.3.6 SATA Configuration SATA Configuration shows information when your SATA interface Storage is installed. www.gigaipc.com...

  • Page 54: Ami Graphic Output Protocol Policy

    3.3.7 AMI Graphic Output Protocol Policy Item Description Choose default monitor output when there are more than one monitor Output Select plugged on the motherboard. www.gigaipc.com...

  • Page 55: Network Stack Configuration

    When Network stack is enabled : Ipv4 PXE Support Disabled : Disables Ipv4 PXE Support Enabled : Enables Ipv4 PXE Support When Network stack is enabled : Ipv6 PXE Support Disabled : Disables Ipv6 PXE Support Enabled : Enables Ipv6 PXE Support www.gigaipc.com...

  • Page 56: Nvme Configuration

    3.3.9 NVMe Configuration NVMe Configuration shows information when your M.2 NVMe PCIe SSD is installed. www.gigaipc.com...

  • Page 57: Amd Cbs

    Control Enabled : Enables Global C-state Control function Auto : System will automatically enter into power saving mode (Default setting) For AMD CPU internal graphic setting GFX Configuration Option items : Auto (Default setting), iGPU Disabled, UMA_SPECIFIED, UMA_AUTO, UMA_GAME_OPTIMIZED www.gigaipc.com...

  • Page 58: Digital Io Port Configuration

    Enabled : If Digital IO Output value/level is modified in OS, they will be memorized and kept. SOGPO_1 (Pin 1) SOGPI_1 (Pin 2) SOGPO_2 (Pin 3) SOGPI_2 (Pin 4) Configure Digital IO Input or Output values for each pin. SOGPO_3 (Pin 5) SOGPI_3 (Pin 6) SOGPO_4 (Pin 7) SOGPI_4 (Pin 8) www.gigaipc.com...

  • Page 59: Chipset

    Power off : Do not power on when the power is back (Default setting) Last state : Restore the system to the state before power loss occures Enable/Disable XHCI Hand-off function XHCI Hand-off Enabled : Enables XHCI Hand-off function (Default setting) Disabled : Disables XHCI Hand-off function www.gigaipc.com...

  • Page 60: Security

    To set up Administrator's password Administrator Minimum length : 3 Password Maximum length : 20 To set up User's password User Password Minimum length : 3 Maximum length : 20 Secure Boot Press <Enter> to configure the advanced items www.gigaipc.com...
  • Page 61 No : Cancel to restore factory settings Reset To Setup Yes : Agree to setup mode Mode No : Cancel to setup mode Enables expert users to modify Secure boot policy variables without full Key Management authentication Press <Enter> to configure the advanced items www.gigaipc.com...
  • Page 62 'UEFI CA' from database from DB No : Cancel to remove 'UEFI CA' from database Restore DB variables to fac tor y Restore DB defaults defaults Yes : Agree to restore DB defaults No : Cancel to restore DB defaults www.gigaipc.com...

  • Page 63: Boot

    Enabled : Enables Full screen LOGO Show on POST screen LOGO Show Disabled : Disables Full screen LOGO Show on POST screen (Default setting) Boot Option #1 Shows the information of the storage that be installed in the system Boot Option #2 Choose/set the boot priority www.gigaipc.com...

  • Page 64: Save & Exit

    Yes : Agree to discard changes and reset and Reset No : Cancel to discard changes and reset Restore/Load default values for all the setup options Restore Defaults Yes : Agree to load optimized defaults No : Cancel to load optimized defaults Boot Override Boot override www.gigaipc.com...
