SPK_OUT (Speaker out connector)
2
Speaker out connector
1
GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
4
Pin 1
Pin No.
Definition
1
Speaker Out R+
2
Speaker Out R-
3
Speaker Out L-
4
Speaker Out L+
