GIGAIPC QBiP-1605A User Manual page 19

Code
1 BKL_CN
2 SPKR
3 F_AUDIO
SODIMM1,
4
SODIMM2
5 SATAPWR
6 SATA
FUSB20_2
7
FUSB20_1
8
9 GPIO_CNT
10 SYS_PANEL
11 M2E
12 M2M
13 AT_CN
14 JCOM2
15 JCOM1
16 COM4
17 COM3
18 COM2
19 COM1
20 MPCIE
21 DC_IN
19
www.gigaipc.com
Back light brightness control connector
Speaker out connector
Audio line-out port
DDR4 SO-DIMM slot#1/slot#2
SATA 6GB/s Power Connector
SATA 6 Gb/s Connector
USB 2.0 header x 1
USB 2.0 header x 1
General Purpose input/output header
Front panel header
M2.2 E-Key for WiFi NGFF
M.2 M Key for NVME/SATA
AT/ATX power mode select jumper
COM2 RI# pin RI#/5V/12V Select
COM1 RI# pin RI#/5V/12V Select
RS232 COM Serial port header
RS232 COM Serial port header
RS232/422/485/5V/12V/RI COM Serial port
header
RS232/422/485/5V/12V/RI COM Serial port
header
Mini PCIE for 3G/4G module
DC IN 1x4pin power connector
GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Description
