Page 1: Sbc Boards
QBiP-1360A/ QBiP-1340A 3.5” SBC Boards www.gigaipc.com... -
Page 2: Copyright Notice
While reasonable efforts have been made in the preparation of this document to assure its accuracy, GIGAIPC assumes no liabilities resulting from errors or omissions in this document, or from the use of the information contained herein. -
Page 3: Acknowledgement
Core, Atom are trademarks of Intel Corporation ITE is a trademark of Integrated Technology Express, Inc. • • IBM, PC/AT, PS/2, and VGA are trademarks of International Business Machines Corporation. All other product names or trademarks are properties of their respective owners. www.gigaipc.com... -
Page 4: Packing List
Before setting up your product, please make sure the following items have been shipped: Item Quantity QBiP-1360A or QBiP-1340A SATA power cable If any of these items are missing or damaged, please contact your distributor or sales representative immediately. www.gigaipc.com... -
Page 5: About This Document
(if any), its specifications, dimensions, jumper/ connector settings/definitions, and driver installation instructions (if any), to facilitate users in setting up their product. Users may refer to the GIGAIPC.com for the latest version of this document. www.gigaipc.com... -
Page 6: Safety Precautions
Make sure the device is installed near a power outlet and is easily accessible. 10. Keep this device away from humidity. 11. Place the device on a solid surface during installation to prevent falls 12. Do not cover the openings on the device to ensure optimal heat dissipation. www.gigaipc.com... - Page 7 18. D O N O T L E AV E T H I S D E V I C E I N A N U N C O N T R O L L E D ENVIRONMENT WITH TEMPERATURES BEYOND THE DEVICE’S PERMITTED STORAGE TEMPERATURES (SEE CHAPTER 1) TO PREVENT DAMAGE. www.gigaipc.com...
-
Page 8: Fcc Statement
Il y a un risque d’explosion si la batterie est remplacée de façon incorrecte. Ne la remplacer qu’avec le même modèle ou équivalent recommandé par le constructeur. Recycler les batteries usées en accord avec les instructions du fabricant et les directives gouvernementales de recyclage. www.gigaipc.com... -
Page 9: China Rohs Requirements (Cn)
China RoHS Requirements (CN) 产品中有毒有害物质或元素名称及含量 GIGAIPC Main Board/ Daughter Board/ Backplane 有毒有害物质或元素 部件名称 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) 印刷电路板 及其电 ○ ○ ○ ○ ○ ○ 子组件 外部信号 连接器 ○ ○ ○ ○... -
Page 10: China Rohs Requirement (En)
China RoHS Requirement (EN) Poisonous or Hazardous Substances or Elements in Products GIGAIPC Main Board/ Daughter Board/ Backplane Poisonous or Hazardous Substances or Elements Component Hexavalent Polybrominated Polybrominated Lead Mercury Cadmium Chromium Biphenyls Diphenyl Ethers (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) PCB &... -
Page 11: Table Of Contents
PCIE_X4 (PCIe Gen4 x4 connector) ....... 26 2.2.6 SATA0 (SATA 6Gb/s connector) ........27 2.2.7 SATAPWR (SATA power connector) ....... 28 2.2.8 FP_AUDIO (Front Audio connector) ......29 2.2.9 SYS_PANEL (Front panel header) ........30 2.2.10 DC_IN (DC IN 1x4 pin power connector) ....31 www.gigaipc.com... - Page 12 Chapter 3 – BIOS Introduction ..............47 The Main Menu............. 48 Advanced ..............49 3.3.1 TPM Configuration ............50 3.3.2 CPU Configuration ............52 3.3.3 SATA Configuration ............54 3.3.4 Super I/O Configuration ..........55 3.3.5 Hardware Monitor ............56 www.gigaipc.com...
- Page 13 3.3.12 Intel(R) Ethernet Controller I226-V - 10:FF:E0:35:B8:DD (M AC a d dres s may v ar ie d bas e d o n di f ferent motherboard)..............63 Chipset ................64 Security ................. 65 Boot ................68 Save & Exit ..............69 www.gigaipc.com...
-
Page 14: Chapter 1 - Product Specifications
Chapter 1 Chapter 1 - Product Specifications www.gigaipc.com... - Page 15 95.2 101.7 www.gigaipc.com...
-
Page 16: Specifications
Specifications QBiP-1360A QBiP-1340A Motherboard 3.5’’ SBC Form Factor 146W x 101.7Dmm Intel® Core™ i7-1360P Processor Intel® Core™ i5-1340P Processor Intel 7, 12 cores, 16 threads, Intel 7, 12 cores, 16 threads, up to 5.0 GHz up to 4.60 GHz TDP 28W... - Page 17 QBiP-1360A QBiP-1340A Motherboard 1 x 4-pin box power connector (DC in +12V~24VDC) 1 x SATA Power header 2 x CPU fan headers 1 x Front panel header Internal I/O 1 x Front panel audio header 1 x 2W Speaker out header 4 x USB 2.0 headers...
-
Page 18: Chapter 2 - Hardware Information
Chapter 2 Chapter 2 – Hardware Information www.gigaipc.com... -
Page 19: Jumpers And Connectors
Jumpers and Connectors 13 14 23 24 www.gigaipc.com... - Page 20 USB 3.2 Gen 2x1 Type C connector (Output) LAN1, LAN2 LAN connector HDMI_DP_1 DP connector (Top) HDMI_DP_2 HDMI connector (Bottom) USB31_1 USB 3.2 Gen 2x1 connector USB31_2 M.2 Slot, 2230 E-key M.2 Slot, 3052 B-key COM1 Serial port header (RS-232 & RI/5V/12V) ME_DIS ME Disable jumper www.gigaipc.com...
- Page 21 Code Description SPK_OUT Speaker out connector JCOM1 COM 1 (COM RI# pin RI#/5V/12V Select) EDP_PWR Embedded Display Port power connector M2M_CPU M.2 Slot, 2280 M-key www.gigaipc.com...
-
Page 22: Cpu_Fan2 (Cpu Fan Connector)
2.2.1 CPU_FAN2 (CPU fan connector) Pin 1 CPU fan Connector Connector PN Vendor 85205-0470N ACES A1250WV-S-04PC JOINT-TECH Connector type 1x4pin header, pitch 1.25mm Pin No. Definition Detect Speed control www.gigaipc.com... -
Page 23: Sodimm1, Sodimm2 (Ddr5 So-Dimm Slot)
2.2.2 SODIMM1, SODIMM2 (DDR5 SO-DIMM Slot) www.gigaipc.com... -
Page 24: Cpu_Fan1 (Cpu Fan Connector)
2.2.3 CPU_FAN1 (CPU fan connector) Pin 1 CPU fan Connector Connector PN Vendor 85205-0470N ACES A1250WV-S-04PC JOINT-TECH Connector type 1x4pin header, pitch 1.25mm Pin No. Definition Detect Speed control www.gigaipc.com... -
Page 25: Edp (Embedded Display Port Connector)
Pin No. Definition Pin No. Definition EDP_TX2+ EDP_TX3- EDP_TX3+ Pin No. Definition Pin No. Definition Connector PN Vendor EDP_TX0- EDP_AUX- 115B20-100020-G4-R STARCONN EDP_TX0+ EDP_AUX+ Connector type 1x20pin header, pitch 0.5mm Hotplug EDP_TX1- Detect Backlight EDP_TX1+ Enable Backlight EDP_TX2- cotrol www.gigaipc.com... -
Page 26: Pcie_X4 (Pcie Gen4 X4 Connector)
RX0_DN CK_REQ CLK_DP CLK_DN SMB_CLK SMB_DATA Pin No. Definition Pin No. Definition PLT_RST# PCIE_WAKE# TX3_DP TX3_DN Connector PN Vendor TX2_DP 115B30-000040-G4-R STARCONN TX2_DN TX1_DP TX1_DN Connector type TX0_DP 1x30pin header, pitch 0.5mm TX0_DN RX3_DP RX3_DN RX2_DP RX2_DN RX1_DP RX1_DN www.gigaipc.com... -
Page 27: Sata0 (Sata 6Gb/S Connector)
2.2.6 SATA0 (SATA 6Gb/s connector) SATA Connector Connector PN Vendor WATF-07DBLBA1UW WINWIN Pin No. Definition www.gigaipc.com... -
Page 28: Satapwr (Sata Power Connector)
2.2.7 SATAPWR (SATA power connector) Pin 1 Hard Disk Power Connector Connector PN Vendor 743-91-045W00 PINREX A2540WR- JOINT-TECH 04PR6NG1N10G Connector type Pin No. Definition 1x4pin header, pitch 2.54mm www.gigaipc.com... -
Page 29: Fp_Audio (Front Audio Connector)
2.2.8 FP_AUDIO (Front Audio connector) Pin 1 Front Audio Connector Connector PN Vendor 725-81-10TW00 PINREX A2004WV-2X05P46 JOINT-TECH Connector type 2x5pin header, pitch 2.0mm Definition Pin Definition MIC_L MIC_JD FAUDIO_JD MIC_R No Connect HPOUT_L HPOUT_R HPOUT_JD www.gigaipc.com... -
Page 30: Sys_Panel (Front Panel Header)
SYS_PANEL (Front panel header) Pin 1 System Panel Header Connector PN Vendor 21P-92-05GB06 PINREX 210-92-05GW5W PINREX Connector type Pin No. Definition 2x5pin header, pitch 2.54mm HDD LED+ Power LED+ HDD LED- Power LED- Power Button+ Reset Power Button- No Connect No Pin www.gigaipc.com... -
Page 31: Dc_In (Dc In 1X4 Pin Power Connector)
2.2.10 DC_IN (DC IN 1x4 pin power connector) Pin 1 DC IN 1x4 pin power connector Connector PN Vendor 753-81-04TW00 PINREX Connector type 1 2 34 1x4pin header, pitch 2.5mm Pin No. Definition POWER IN POWER IN www.gigaipc.com... -
Page 32: Fusb1, Fusb2 (Usb2.0 Headers)
2.2.11 FUSB1, FUSB2 (USB2.0 headers) FUSB1 Pin 1 FUSB2 USB 2.0 Header Connector PN Vendor 210-92-05GB04 PINREX PH10R53BAZ009 HORNGTONG Connector type 2x5pin header, pitch 2.54mm 9 10 Pin No. Definition No Pin No Connect www.gigaipc.com... -
Page 33: Battery (Battery Cable Connector)
2.2.12 BATTERY (Battery cable Connector) Pin 1 Battery cable Connector Connector PN Vendor 85205-0270L ACES A1250WV-S-02PC JOINT-TECH Connector type 1x2pin header, pitch 1.25mm Pin No. Definition 3.3V www.gigaipc.com... -
Page 34: Usb3Cp (Usb 3.2 Gen 2X1 Type C Connector)
2.2.14 USB3CM (USB 3.2 Gen 2x1 Type C connector) Input Output USB Type C Connector Connector PN Vendor WU3CR- WINWIN 24A5L1CU5T41 Pin No. Definition Pin No. Definition TX1+ TX2+ TX1- TX2- VBUS VBUS VBUS VBUS RX2- RX1- RX2+ RX1+ www.gigaipc.com... -
Page 35: Lan1, Lan2 (Lan Connector)
State Description Orange On 2.5Gbps data rate Green On 1Gbps data rate 100M & 10Mbps data rate Link / Connection/ Activity LED Speed LED Pin No. Definition Connector PN Vendor TX+_D1 RB1-GB-0009 TX-_D1 RX+_D2 BI+_D3 BI-_D3 RX-_D2 BI+_D4 BI-_D4 www.gigaipc.com... -
Page 36: Connector)
Pin No. Definition Pin No. Definition Pin No. Definition HDMI_D2+ DATA_0P DATA_3N HDMI_D2- HDMI_SCL DATA_0N CONFIG1 HDMI_D1+ HDMI_SDA DATA_1P AUX_P HDMI_D1- DATA_1N HDMI_D0+ HDMI_HPD DATA_2P AUX_N DP HPD HDMI_D0- DATA_2N HDMI_CLK+ DATA_3P DP PWR Connector PN Vendor HDMI_CLK- DPHDDPHD0172201AN0 FENYING www.gigaipc.com... -
Page 37: Usb31_1, Usb31_2 (Usb 3.2 Gen 2X1 Connector)
2.2.17 USB31_1, USB31_2 (USB 3.2 Gen 2x1 Connector) USB31_2 USB31_1 USB Connector Connector PN Vendor 18-A5950-6A33-A TCONN Definition Definition USB_D- USB_D- USB_D+ USB_D+ USB3_RX- USB3_RX- USB3_RX+ USB3_RX+ USB3_TX- USB3_TX- USB3_TX+ USB3_TX+ www.gigaipc.com... -
Page 38: M2E (M.2 Slot, 2230 E-Key)
M.2 E Key Connector WLAN_RXP CL_DATA WLAN_RXN CL_CLK CLK_DP CLK_DN Pin No. Definition Pin No. Definition SUSCLK CLK_REQ PLT_RST# PCIE_WAKE BT_Disable# USB_D+ WIFI_Disable# USB_D- Connector PN Vendor Pin No. Definition Pin No. Definition APCI0095-P002A LOTES 80152-8521 BELLWETHER WLAN_TXP WLAN_TXN www.gigaipc.com... -
Page 39: M2B (M.2 Slot, 3052 B-Key)
WWAN_ USB D+ Disable USB D- COEX3 COEX2 COEX1 Pin No. Definition Pin No. Definition 1.8V UMI_DET M2B_DET M2B_WAKE 3.3V M2B_DRP 3.3V WWAN_ 3.3V Disable2 Connector PN Vendor USB3 RXN USB3_RXP SIM_RST# 80149-8521 BELLWETHER SIM_CLK 2E0BC21-S85BB-7H FOXCONN USB3_TXN SIM_DATA www.gigaipc.com... -
Page 40: Com1 (Serial Port Header, Rs-232 & Ri/5V/12V)
2.2.20 COM1 (Serial port header, RS-232 & RI/5V/12V) Pin 1 Serial Port Cable Connector Connector PN Vendor 725-81-10TW00 PINREX A2004WV-2X05P46 JOINT-TECH Connector type 2x5pin header, pitch 2.0mm Definition Definition No Connect RI/ 5V/ 12V www.gigaipc.com... -
Page 41: Me_Dis (Me Disable Jumper)
2.2.21 ME_DIS (ME Disable jumper) ME Disable Connector Connector PN Vendor 220-96-02GBK1 PINREX Connector type 1x2pin header, pitch 2.0mm ME Disable jumper Enable (Default) Disable (Close) www.gigaipc.com... -
Page 42: Spk_Out (Speaker Out Connector)
2.2.22 SPK_OUT (Speaker out connector) Pin 1 Speaker out Connector Connector PN Vendor A2001WV-04P146 JOINT-TECH Connector type 12 34 1x4pin header, pitch 2.0mm Pin No. Definition Speaker Out L+ Speaker Out L- Speaker Out R- Speaker Out R+ www.gigaipc.com... -
Page 43: Jcom1 (Com1 Ri# Pin Ri#/5V/12V Select)
2.2.23 JCOM1 (COM1 RI# pin RI#/5V/12V Select) Pin 1 JCOM1 Jumper Select Connector PN Vendor 222-97-03GBE1 PINREX 1-2 Close: 5V (Power COM) Connector type 2x3pin header, pitch 2.0mm 3-4 Close: RI (Stand COM) (Default-Setting) 5-6 Close: 12V (Power COM) www.gigaipc.com... -
Page 44: Edp_Pwr (Embedded Display Port Power Connector)
2.2.24 ED P_ P WR (Emb e d de d D i s p lay Po r t p ower connector) Pin 1 Embedded Display Port power Connector PN Vendor connector 85205-0770N ACES A1250WV-S-07PC JOINT-TECH Connector type 1x7pin header, pitch 1.25mm Pin No. Definition www.gigaipc.com... -
Page 45: M2M (M.2 Slot, 2280 M-Key)
SATA_TXP PLT_RST 3.3V CK_REQ PCIE_RX3- CLK_N PCIE_WAKE# PCIE_RX3+ CLK_P M2_LED PCIE_TX3- 3.3V Pin No. Definition Pin No. Definition PCIE_TX3+ 3.3V SUSCLK 3.3V M2_SSD_ PCIE_RX2- 3.3V 3.3V Detect PCIE_RX2+ 3.3V 3.3V PCIE_TX2- PCIE_TX2+ Connector PN Vendor PCIE_RX1- 2E0BC41-C85CM-LH FOXCONN PCIE_RX1+ www.gigaipc.com... -
Page 46: Chapter 3 - Bios
Chapter 3 Chapter 3 – BIOS www.gigaipc.com... -
Page 47: Introduction
Execute command or enter the submenu Increase the numeric value or make ＋ changes Decrease the numeric value or make – changes General Help Previous Values Load Optimized Defaults Settings Save changes & Exit the BIOS Setup program Exit the BIOS Setup program www.gigaipc.com... -
Page 48: The Main Menu
ME FW version Shows ME firmware version Set the Date for the system System Date (Format : Weekday - Month - Day - Year) Set the time for the system System Time (Format : Hour - Minute - Second) www.gigaipc.com... -
Page 49: Advanced
Advanced The Advanced menu is to configure the functions of hardware settings through submenu. Use arrow keys to move among the items, and press <Enter> to access into the related submenu. www.gigaipc.com... -
Page 50: Tpm Configuration
3.3.1 TPM Configuration Use TPM Configuration submenu to choose TPM interface. Item Description PTT : Internal TPM TPM Device dTPM : External TPM (When using External TPM module or having Selection TPM chip on MB)(Default setting) www.gigaipc.com... - Page 51 Item Description Security Device Enabled : Enables TPM feature (Default setting) support Disabled : Disables TPM feature None : No execution will be conducted (Default setting) Pending operation TPM clear : Set to clear data on TPM www.gigaipc.com...
-
Page 52: Cpu Configuration
Enabled : Enables Intel Trusted Execution Technology (Intel® TXT) To speed up CPU frequency transition time from basic frequency to Intel(R) Speed maximum frequency. Shift Technology Enabled : Enables Intel(R) Speed Shift Technology (Default setting) Disabled : Disables Intel(R) Speed Shift Technology www.gigaipc.com... - Page 53 Enabled : Enables Turbo Mode (Default setting) Turbo Mode Disabled : Disables Turbo Mode Command CPU to enter into low power consumption mode when CPU is under idle mode. C states Enabled : Enables C states (Default setting) Disabled : Disables C states www.gigaipc.com...
-
Page 54: Sata Configuration
Intel VMD feature helps you to control and manage NVMe PCIe SSD. / Enable VMD Enabled : Enables Intel VMD feature controller Disabled : Disables Intel VMD feature (Default setting) Serial ATA Port shows 2.5" SATA HDD/SSD information shows M.2 SATA interface SSD information www.gigaipc.com... -
Page 55: Super I/O Configuration
Serial Port 1 Enabled : Enables allows you to configure the serial port settings Configuration Disabled : if Disabled, displays no configuration for the serial port Device settings : Display the specified Serial Port base I/O address and IRQ www.gigaipc.com... -
Page 56: Hardware Monitor
CPU Fan Speed Normal : Fan speed set by BIOS default(Default setting) Control Full Speed : Set Fan operates at full speed CPU temperature Shows current CPU temperature System Shows current system temperature temperature Fan Speed Shows current CPU fan Speed www.gigaipc.com... -
Page 57: S5 Rtc Wake Settings
Enable or Disable System to wake on a specific time. Disabled : Disables system to wake on a specific time (Default Wake system setting) from S5 Fixed Time : Enables system to wake on a specific time (Format : hr : min : sec) www.gigaipc.com... -
Page 58: Network Stack Configuration
Disabled : Disables Ipv6 PXE Support Enabled : Enables Ipv6 PXE Support PXE boot wait time Wait time in seconds, or use ESC key to abort the PXE boot. Media detect count Number of times the presence of media will be checked. www.gigaipc.com... -
Page 59: Nvme Configuration
3.3.8 NVMe Configuration NVMe Configuration shows information when your M.2 NVMe PCIe SSD is installed. www.gigaipc.com... -
Page 60: Offboard Sata Controller Configuration
3.3.9 Offboard SATA Controller Configuration www.gigaipc.com... -
Page 61: Tls Auth Configuration
Press [Enter] to configure advanced items : Server CA Configuration : Enroll Cert : 1. Enroll Cert Using File Enroll Cert 2. Cert GUID : Input digit character in 11111111-2222-3333-4444-1234567 890ab format. 3. Commit Changes and Exit 4. Discard Changes and Exit www.gigaipc.com... -
Page 62: Intel(R) Ethernet Controller I226-V - 10:Ff:e0:35:B8:Dc
3.3.11 Intel(R) Ethernet Controller I226-V - 10:FF:E0:35:B8:DC (MAC address may varied based on different motherboard) Shows Intel Ethernet controller information NOTE：MAC address may varied based on different motherboard www.gigaipc.com... -
Page 63: Intel(R) Ethernet Controller I226-V - 10:Ff:e0:35:B8:Dd
3.3.12 Intel(R) Ethernet Controller I226-V - 10:FF:E0:35:B8:DD (MAC address may varied based on different motherboard) Shows Intel Ethernet controller information NOTE：MAC address may varied based on different motherboard www.gigaipc.com... -
Page 64: Chipset
Enable/Disable Watchdog Timer function Watchdog Timer Enabled : Enables Watchdog Timer function Disabled : Disabled Watchdog Timer function (Default setting) Enable/Disable BIOS Lock function BIOS Lock Enabled : Enables BIOS Lock function (Default setting) Disabled : Disabled BIOS Lock funtion www.gigaipc.com... -
Page 65: Security
To set up Administrator's password Administrator Minimum length : 3 Password Maximum length : 20 To set up User's password User Password Minimum length : 3 Maximum length : 20 Secure Boot Press <Enter> to configure the advanced items www.gigaipc.com... - Page 66 No : Cancel to restore factory settings Reset To Setup Yes : Agree to setup mode Mode No : Cancel to setup mode Enables expert users to modify Secure boot policy variables without Key Management full authentication Press <Enter> to configure the advanced items www.gigaipc.com...
- Page 67 TimeStamps (dbt) Enroll Efi Allow the image to run in Secure Image Boot mode OsRecovery Signatures Export Copy NVRAM content of Secure Boot (dbr) Secure Boot variables to files in a root folder on a variables file system device www.gigaipc.com...
-
Page 68: Boot
Enable/Disable Built-in EFI Shell Built-in EFI Shell Enabled : Enables Built-in EFI Shell Disabled : Disables Built-in EFI Shell (Default setting) Shows the information of the storage that be installed in the system Boot Option #1 Choose/set the boot priority www.gigaipc.com... -
Page 69: Save & Exit
Yes : Agree to load optimized defaults No : Cancel to load optimized defaults Enable/Disable Me FW image re-flash function Me FW Image Enabled : Enables Me FW image re-flash function Re-Flash Disabled : Disables Me FW image re-flash function (Default setting) www.gigaipc.com...
