7500 Sediment Filter Installation & Startup Guide
Enquiry/Setting button and use the Up/Down buttons to set it to [2-10:00]. Press
Enquiry/Setting to confirm the backwash time.
6) To change the Fast Rinse Time:
The fast rinse time is the amount of time (in minutes) that the system will rinse for.
For a neutralizer filter, set the fast rinse time to 6 minutes [3-06:00]. To change this, set the
programming mode to Fast Rinse Time ( [3-10:00] and fast rinse icon displayed ). Press the
Enquiry/Setting button and use the Up/Down buttons to set it to [3-06:00]. Press
Enquiry/Setting to confirm the fast rinse time.
7) To change the Signal Output Mode
The signal output mode refers to when the system receives external function.
Leave this at its default, [b-01].
After configuring, press the Manual/Return button to exit programming mode.
Press the Menu/Enter Button until all steps have been viewed. The Program Mode will
be exited and normal operation resumed. If no buttons are pressed for 60 seconds or
longer in Master Programming Mode it will be exited automatically.

Initial Backwash

1 After programming, the system must be run through an initial backwash.
2 Close inlet valve B and outlet valve C, and open the bypass valve A. From the initial valve
menu, press the Manual/Return button to enter into the backwashing. When the backwash
icon is displayed, slowly open the inlet valve B to a quarter position to make the water flow
into the resin tank; you should be able to hear the sound of air escaping from the drain
pipeline. After all the air is out of the pipeline, open inlet valve B and clean the foreign
materials in the tank until the water is clean.
3 If possible verify that the backwash flow corresponds with the size of your system below.
You can easily run the drain hose to a bucket and using a watch verify the flow rate in
gallons per minute. An adequate backwash is critical to properly clean the Chemsorb media
and prevent it from cementing together.
Page 10
0.75 CF 5 GPM
