7500-REV2.5 Tannin Filter Installation Guide
Thank you for purchasing a Clean Water System!
Please review this start‐up guide entirely before beginning
to install your system, and follow the steps outlined for
best results.
Minimum pressure of 30 PSI recommended.
Maximum pressure recommended 80 PSI.
For indoor installation only.
Protect from sunlight, rain, and freezing.
Questions?
Call us toll‐free: 1‐888‐600‐5426 or 1‐831‐462‐8500
Email us:
support@cleanwaterstore.com
See more information on our website:
www.cleanwaterstore.com/resources
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Clean Water Systems 7500-REV2.5
Summary of Contents for Clean Water Systems 7500-REV2.5
- Page 1 Clean Water Made Easy www.cleanwaterstore.com 7500-REV2.5 Tannin Filter Installation Guide Thank you for purchasing a Clean Water System! Please review this start‐up guide entirely before beginning to install your system, and follow the steps outlined for best results. Minimum pressure of 30 PSI recommended.
-
Page 2: Table Of Contents
Table of Contents Packing Lists ..............................3 Pre‐Installation .............................. 4 Best Practices for Piping & Drain Installation: ....................4 How the Bypass Valve Works ........................5 Installation of Your System in Copper or Metal Piping Systems: ..............5 How Your Tannin Filter Works: ........................6 Diagram of Typical Installation Well Water .................... -
Page 3: Packing Lists
7500-REV2.5 Tannin Filter Installation & Startup Guide Packing Lists All systems include: 7500‐REV2.5 control valve, brine tank, small tube of silicone grease, bypass valve, 1” pipe connectors, power supply, funnel for adding tannin resin, top screen, start‐up guide, and items... -
Page 4: Pre-Installation
7500-REV2.5 Tannin Filter Installation & Startup Guide Pre-Installation 1. Review your packing list and make sure you have received all the parts before installation. 2. If you are going to be turning off the water to the house and you have an electric water heater, shut off the power to the water heater before beginning installation in case water heater is accidentally drained. -
Page 5: How The Bypass Valve Works
7500-REV2.5 Tannin Filter Installation & Startup Guide How the Bypass Valve Works Turn knob so the valve is bypassed when installing. When you go to start up system turn the bypass SLOWLY to let water in and put in service. -
Page 6: How Your Tannin Filter Works
7500-REV2.5 Tannin Filter Installation & Startup Guide How Your Tannin Filter Works: In the Tannin Filter, water enters the top of the tank and flows down through the media and up the distributor tube. Hardness minerals are attracted to the resin beads. -
Page 7: Tannin Tank Assembly And Installation Instructions
7500-REV2.5 Tannin Filter Installation & Startup Guide Tannin Tank Assembly and Installation Instructions: 1. Wrap the top of distributor tube with electrical or duct tape so that no gravel or Tannin resin will go down the distributor tube when adding the media. - Page 8 7500-REV2.5 Tannin Filter Installation & Startup Guide 13. Connect black 3/8” tubing to brine tank. 14. Hook up drain line tubing to drain. If needed heat up the tubing with warm water or a hair dryer to make it easier to slip over the barbed fitting on the drain port.
-
Page 9: Programming Your Valve And Setting Time And Days For Backwash
7500-REV2.5 Tannin Filter Installation & Startup Guide Programming Your Valve and Setting Time and Days for Backwash How to Start a Manual Backwash: Press the Back / Regen button Pressing “Back Regen” at any time results in an immediate manual regeneration. -
Page 10: Set Time Of Day
7500-REV2.5 Tannin Filter Installation & Startup Guide Set Time of Day 1. If LOCK icon is lit, press, and hold both UP and DOWN buttons for 3 seconds to unlock keypad. 2. Then press the MENU/CONFIRM button to enter the main menu. -
Page 11: Set Service Days
7500-REV2.5 Tannin Filter Installation & Startup Guide Set Service Days Set for every 3 to 4 days. In some cases it may need to be set to every 1 to 2 days. Set Regen Time The time tannin filter will backwash. Default is 2:00 AM Set Backwash Time Length Set for 10 minutes. -
Page 12: Advanced Programming Mode
7500-REV2.5 Tannin Filter Installation & Startup Guide Advanced Programming Mode The Advanced Programming Mode allows you to set the Regen Cycle and Regen Mode. Skip this for most applications as your tannin system has already been set to correct modes. -
Page 13: 7500-Rev2.5 Water Conditioners Limited Warranty
7500-REV2.5 Tannin Filter Installation & Startup Guide 7500-REV2.5 Water Conditioners Limited Warranty We warrant this water filter when installed according to factory recommendations, to be free from defects in materials and workmanship as follows: ‐‐‐‐‐‐‐‐‐‐Limited Warranty‐‐‐‐‐‐‐‐‐‐ This water conditioner unit is comprised of the finest industry components available. Each individual component used in the assembly of our equipment is covered by the original equipment manufacturer’s warranty.
