2.4 SuperSPARC Modules

2-4
Standoff
Locked Unlocked
Figure 2-3 Locking and Unlocking Standoffs
The system board can have zero, one, or two modules. Refer to Figure 2-4.
If you are adding SuperSPARC modules to a system, fill all A slots first, before
filling the B slots. Start with the lowest-numbered system boards.
SPARCcenter 2000 System Board Manual—October 1994
SBus card or
SuperSPARC module
Standoff
Tip
Flange
