Figure 5 – Atmel
®
QTouch16 sensor board displayed on CPU monitor
Figure 6 – Complete set-up for the Atmel QTouch16 sensor board: The sensor board is connected to the Atmel ATXMEGA128A1, which in turn
is connected to the interface board
