Summary of Contents for Atmel QT600
- Page 1 Atmel QT600 Quick Start Guide Touch Solutions...
-
Page 2: Download The Latest Software
Atmel QTouch8 Atmel ATXMEGA128A1 Atmel ATtiny88 Atmel QTouch16 Figure 1 – The Atmel QT600 Evaluation Kit includes these microcontroller and sensor boards The photo above shows three sets of boards (sensor board and corresponding microcontroller board): • QTouch8 with the ATtiny88 •... - Page 3 Figure 2 – Close-up of the Atmel QT600 interface board and location of the VTG Note: On the main QT600 control board, make sure the jumper is in place on the VTG. The board should be configured as above: Connect the kit modules...
- Page 4 Just below (under Touch Data Read Control), click Start Reading 1.17.3 QTouch Studio is now reading touch data from your QT600. You will see changes in the Virtual Kit View as you touch the sensor regions on the QTouch8 board.
- Page 5 Touch Solutions Figure 3 – Atmel QTouch8 Sensor Figure 4 – Complete Set-up for the Atmel QTouch8 sensor board: The sensor board is Board Displayed on CPU Monitor connected to the ATtiny88, which in turn is connected to the interface board...
- Page 6 Figure 5 – Atmel ® QTouch16 sensor board displayed on CPU monitor Figure 6 – Complete set-up for the Atmel QTouch16 sensor board: The sensor board is connected to the Atmel ATXMEGA128A1, which in turn is connected to the interface board...
- Page 7 Figure 7 – Atmel QMatrix 8x8 sensor board displayed on CPU monitor Figure 8 – Complete set-up for the Atmel QMatrix 8x8 sensor board: The sensor board is connected to the Atmel ATmega324, which in turn is ® connected to the interface board...
- Page 8 Disclaimer: The information in this document is provided in connection with Atmel products. No license, express or implied, by estoppel or otherwise, to any intellectual property right is granted by this document or in connection with the sale of Atmel...
