Parts List - Linear Technology DC1659A Quick Start Manual

PARTS LIST

ITEM QTY REFERENCE
1 1 C1
2 1 C2
3 2 C4, C5
4 1 C6
5 1 C7
6 3 E1, E2, E8
7 7 E3-E7, E9, E10
8 1 JP1
9 1 JP1
10 2 LED1, LED2
11 1 R1
12 1 R2
13 1 R3
14 3 R4, R5, R14
15 1 R6
16 2 R7, R8
17 1 R10
18 1 R11, R22
19 1 R12
20 1 R13
21 1 R15
22 1 R16, R23
23 1 R17
24 3 R18, R19, R21
25 2 R20, R9
26 1 SW1
28 1 U2
29 1 U3
30 1 U4
DC1659A-A
1 1 U1
DC1659A-B
1 1 U1
Arrow.com. Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from Downloaded from
DEMO MANUAL DC1659A
PART DESCRIPTION
Capacitor, 1μF 20% 1206 100V X7R
Capacitor, 0.47μF 20% 0603 16V X5R
Capacitor, 0.1μF 20% 0402 10V X5R
Capacitor, 0.1μF 20% 0603 X5R Optional
Capacitor, 0.1μF 10% 0603 100V X7R
Turret Terminal
Turret Terminal
Header, 3-Pin, 2mm
Shunt
Red1206 LED
Resistor, 2k 1% 0603 1/16W
Resistor, 6.65k 1% 0603 1/16W
Resistor, 1.33k 1% 0603 1/16W
Resistor, 10k 5% 0402 1/16W
Resistor, 118k 1% 0402 1/16W
Resistor, 1k 5% 0603 1/16W
Resistor, 100Ω 1% 0603 1/16W
Resistor, 0Ω 0402 1/16W
Resistor, 13.7k 1% 0402 1/16W
Resistor, 249k 1% 0402 1/16W
Resistor, 0.1Ω 1% 2512 2W
Resistor, 1M 1% 0402 1/16W
Resistor, 392k 1% 0402 1/16W
Optional
Resistor, 0Ω 0603 1/16W
Switch, Pushbutton
IC, LT3010EMS8E#PBF
IC, LT6993CS6-1#PBF
IC, LT6991CS6#PBF
IC, LT6109IMS-1
IC, LT6109IMS-2
MANUFACTURER/PART NUMBER
TDK/C3216X7R2A105M
AVX/0603YD474MAT2A
Taiyo Yuden/LMK105BJ104MV-F
Murata/GRM188R72A104KA35D
Mill Max 2501-2-00-80-00-00-07-0
Mill Max 2308-2-00-80-00-00-07-0
SAMTEC TMM-103-02-L-S
SAMTEC 2SN-BK-G
Panasonic/LN1251C
AAC/CR16-2001FM
Vishay/CRCW06036K65FKEA
AAC/CR16-1331FM
AAC/CR05-103JM
AAC/CR05-1243FM
Vishay/CRCW04021K00JNED
Vishay/CRCW0603100RFKEA
Vishay/CRCW04020000Z0ED
AAC/CR05-1372FM
AAC/CR05-2493FM
IRC/LR2512LF-01-R100-F
AAC/CR05-1004FM
AAC/CR05-3923FM
AAC/CJ06-000M
Panasonic/EVQPPDA25
Linear Technology Corp.
Linear Technology Corp.
Linear Technology Corp.
Linear Technology Corp. LT6109IMS-2
Linear Technology Corp. LT6109IMS-2
