ClearSpan™
Commercial Canopies
Photo may show a different but similar model.
CLEARSPAN
COMMERCIAL CANOPIES
™
STK#
2420CC
2430CC
2440CC
2450CC
2460CC
DIMENSIONS
24' W x 20' L
24' W x 30' L
24' W x 40' L
24' W x 50' L
24' W x 60' L
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ClearSpan 2420CC
Summary of Contents for ClearSpan 2420CC
- Page 1 COMMERCIAL CANOPIES ™ ClearSpan™ Commercial Canopies Photo may show a different but similar model. STK# DIMENSIONS 2420CC 24’ W x 20’ L 2430CC 24’ W x 30’ L 2440CC 24’ W x 40’ L 2450CC 24’ W x 50’ L ©2010 ClearSpan™...
-
Page 2: Safety Precautions
• Never erect the structure under power lines. • Identify whether underground cables and pipes are Thank you for purchasing this ClearSpan™ shelter. When present before preparing the site or anchoring the properly assembled and maintained, this product will structure. -
Page 3: Assembly Procedure
These words and phrases are common to most joints and to fasten brackets to rafters. ClearSpan™ shelters and identify the different parts of the shelter. (Some are used in this document. Others may not apply to this particular shelter.) These terms describe the shipped parts and can also be found on the materials list/spec sheets included with the shipment. -
Page 4: Required Tools
CLEARSPAN COMMERCIAL CANOPIES ™ REQUIRED TOOLS ALTERNATIVE ASSEMBLY INFORMATION The following list identifies the main tools needed to These instructions describe assembling the entire roof assemble the shelter. Additional tools and supports may be section of the shelter first. The frame is then lifted and the needed depending on the structure, location, and legs added. For long shelters or when limited assistance application. - Page 5 CLEARSPAN COMMERCIAL CANOPIES ™ The following graphics and photos will help you identify the different parts and show you how they are used. (Not all parts are shown.) FA4470B QH1402 Tek screw Band Clamp 100442 QH1061 103620b Nut Setter Ratchet...
- Page 6 CLEARSPAN COMMERCIAL CANOPIES ™ ADDITIONAL PARTS IDENTIFICATION NOTES In some instances, there can be differences between the parts that are shown and referenced in the instructions and the parts that are shipped with the shelter. These differences do not affect the integrity of the shelter, but can change the assembly procedures.
-
Page 7: Frame Diagram
CLEARSPAN COMMERCIAL CANOPIES ™ ClearSpan ™ WeatherShield Commercial Canopies End Rafter Purlins Interior Rafter Horizontal Strut FRAME DIAGRAM NOTE: Diagram above may show a shelter that differs in length or width from the actual frame. Frame above is used for illustration purposes. -
Page 8: Frame Assembly
CLEARSPAN COMMERCIAL CANOPIES ™ LAY OUT THE BUILDING SITE Frame Assembly Procedure After the site is prepared, identify the location of the shelter corners to help square the frame after it is assembled. Arrange the roof pipes on the ground adjacent to the correct couplers needed to assemble the roof. - Page 9 CLEARSPAN COMMERCIAL CANOPIES ™ FRAME ASSEMBLY (CONTINUED) SQUARE THE ASSEMBLED FRAME Gather the parts: Add horizontal struts (#QH1308) between rafter pipes at each rafter. Secure at each end using a band clamp • Measuring tape and assistants as shown below.
- Page 10 CLEARSPAN COMMERCIAL CANOPIES ™ ANCHOR THE SHELTER INSTALL MAIN COVER At this point, anchor the shelter. Consult the MUST READ Gather the parts: document for anchoring information and suggestions. • Ratchets (1" 4000lb) Please call customer service at 1-800-245-9881 for additional anchoring information.
- Page 11 CLEARSPAN COMMERCIAL CANOPIES ™ INSTALL COVER (CONTINUED) At the ends, locate the black straps. Using the straps as guides, fasten ratchets to the outside of the end Locate the cover ends with strapping and align cover rafter legs using a Tek screw for each ratchet.
- Page 12 For replacement or missing parts, call 1-800-245-9881 for assistance. NOTE: With the exception of Truss Arch buildings, ClearSpan™ shelters and greenhouses do not have any NOTE: It may be necessary to remove excess strap if it tested loading criteria. binds up in the ratchet.
- Page 13 QUICK START GUIDE 6'-5" Endwall 24' Wide Commercial Canopies Height 22'-10 11/16" Width FRONT Grid Represents 12" Squares 2420CC (24' x 20') 2430CC (24' x 30') 2440CC (24' x 40') 2450CC (24' x 50') 2460CC (24' x 60') Revision date: 06.22.10...
- Page 14 CLEARSPAN COMMERCIAL CANOPIES ™ Revision date: 06.22.10...
- Page 15 CLEARSPAN COMMERCIAL CANOPIES ™ Revision date: 06.22.10...
- Page 16 CLEARSPAN COMMERCIAL CANOPIES ™ Revision date: 06.22.10...
- Page 17 CLEARSPAN COMMERCIAL CANOPIES ™ Revision date: 06.22.10...
- Page 18 CLEARSPAN COMMERCIAL CANOPIES ™ Revision date: 06.22.10...
- Page 19 CLEARSPAN COMMERCIAL CANOPIES ™ Revision date: 06.22.10...
- Page 20 CLEARSPAN COMMERCIAL CANOPIES ™ Revision date: 06.22.10...
- Page 21 CLEARSPAN COMMERCIAL CANOPIES ™ Revision date: 06.22.10...
