Summary of Contents for ClearSpan 103434
- Page 1 Poly Shelters Instruction Manual Backyard Canopy 10' Wide x 20' Long SKU #103434 © 2004 ClearSpan All rights reserved. Reproduction prohibited without written permission. Rev: 21 June 04...
- Page 2 • The ClearSpan Backyard Canopy is a temporary structure and is not designed as a permanent structure. • The structure is not meant to support ice or snow. As such, ClearSpan does not guarantee this canopy if used in ice or snow.
- Page 3 IMPORTANT - Read Anchoring Instructions You must read the anchoring instructions packed with your kit prior to shelter assembly! Selecting a Location It is important to select a proper location for your poly shelter. While the location may have been predetermined before you even ordered your shelter, you may want to “improve”...
- Page 4 Parts Identification and Quantities (8) “A” Rafter Poles (9) “B” Long Poles (8) “C” Leg Poles (6) 3-Way Couplers (6) 4-Way Couplers (8) Base Feet (8) Base Feet Nuts & Bolts (42) Wing Nuts for Couplers (53) Ball Bungies (1) Canopy Cover Note: Illustrations are not to scale.
- Page 5 Section B - Assembly Step 1: Assemble the ridge using (3) of the “B” sections with (2) 4-way couplers between them. Step 2: Add a 3-way coupler to each end of the ridge. Step 3: Add a pair of “A” rafters to each coupler, one on each side of the ridge (8 total). Step 4: Add a 3-way coupler in each corner, and a 4-way coupler at the ends of the two middle raf- ters on each side.
- Page 6 Step 10: Anchor your shelter using an approved anchoring method. While anchors are not supplied in your kit, the type appropriate for your installation may be purchased from ClearSpan . Call us at 1-800-245-9881 if you need advice from one of our shelter experts prior to purchase.
- Page 7 Section C - Shelter Use and Maintenance • Cover must be kept taut - Check and adjust tension periodically. • Do not allow snow or ice to accumulate on the cover. • Use a broom, mop, or brush to clear any ice or snow from the cover. •...
