ClearSpan
Storage Master Elite Garage
Photo may show a different but similar model.
™
STK#
PB03000R5 12' W x 20' L
PB03002R5 12' W x 25' L
PB03004R5 12' W x 30' L
CLEARSPAN
GARAGES
™
DIMENSIONS
1
Advertisement
Table of Contents
Related Manuals for ClearSpan PB03000R5
Summary of Contents for ClearSpan PB03000R5
- Page 1 ™ Storage Master Elite Garage Photo may show a different but similar model. STK# DIMENSIONS PB03000R5 12' W x 20' L PB03002R5 12' W x 25' L ©2010 ClearSpan™ All Rights Reserved. Reproduction PB03004R5 12' W x 30' L is prohibited without permission.
-
Page 2: Safety Precautions
• Identify whether underground cables and pipes are present before preparing the site or anchoring the Thank you for purchasing this ClearSpan™ shelter. When structure. properly assembled and maintained, this product will provide years of reliable service. These instructions include •... -
Page 3: Assembly Procedure
These words and phrases are common to most • Tek Screw: A self-tapping fastener used to secure pipe ClearSpan™ shelters and identify the different parts of the joints and to fasten brackets to rafters. shelter. (Some are used in this document. Others may not apply to this particular shelter.) -
Page 4: Required Tools
CLEARSPAN GARAGES ™ ANCHORING INSTRUCTIONS REQUIRED TOOLS Prior to assembling this shelter, please read the MUST The following list identifies the main tools needed to READ document included with the shipment. assemble the shelter. Additional tools and supports may be... - Page 5 CLEARSPAN GARAGES ™ The following graphics and photos will help you identify the different parts. (Some parts are not shown.) FA4482B 100441 102921B Tek Screw Nut Setter Neo-bonded Galvanized Washer QH1330 104075 Variable Angle 1.75" x 1.75" Square Bracket Tube Insert...
- Page 6 CLEARSPAN GARAGES ™ ClearSpan ™ Storage Master Elite Garage OVERVIEW This section describes assembling your garage. For details, consult the remainder of these instructions. See illustration below to identify main parts of the shelter. 1. Locate the required parts for each assembly procedure.
- Page 7 CLEARSPAN GARAGES ™ LAY OUT THE BUILDING SITE ASSEMBLE AND POSITION BASE RAILS After the site is prepared, marking the ground where the NOTE: Assistance is required to assemble the garage shelter will be situated and identifying the location of frame.
- Page 8 CLEARSPAN GARAGES ™ 5. Center a square tube fitting (#104624) on each ASSEMBLE AND POSITION BASE RAILS (continued) remaining mark and secure the fitting to the rail using ATTACH 104624 FITTINGS (RAFTER FEET) Tek screws. Gather the parts: • Assembled base rails Square Tube Fitting •...
-
Page 9: Rafter Assembly
CLEARSPAN GARAGES ™ RAFTER ASSEMBLY Assemble the End Rafters Gather the parts: Complete the following steps to assemble the two (2) end rafters. • Rafter pipe ( #12CP20P1) NOTE: The two (2) end rafters are assembled using 3-way • Rafter pipe (#12CP20P3) square tube fittings (#104626) positioned between the leg •... -
Page 10: Frame Assembly
CLEARSPAN GARAGES ™ RAFTER ASSEMBLY (continued) FRAME ASSEMBLY Interior Rafters The following instructions assume the 104624 fittings (rafter feet) are properly spaced on each base rail. 1. Select the tubing for the first interior rafter assembly and position it on the ground as shown. - Page 11 CLEARSPAN GARAGES ™ FRAME ASSEMBLY (continued) SQUARE THE ASSEMBLED FRAME Complete these steps: 4. Carefully stand the first interior rafter and place the leg pipes on the next set of 104624 square tube fittings. 1. Perform a final square of the frame by measuring diagonally (corner-to-corner) at the base and verify that 5.
- Page 12 CLEARSPAN GARAGES ™ ANCHOR THE SHELTER END CONDUIT ASSEMBLY At this point in the assembly process, anchor the Gather the parts: assembled frame. Once the frame assembly is anchored • Pipe 1.315'' x 75'' swaged (#131S075) properly, continue with these instructions.
- Page 13 CLEARSPAN GARAGES ™ 2. On the zippered end panel, insert the end conduit ATTACH END PANEL ASSEMBLIES through the two side panels of the end panel (as shown Gather the parts: below) and not through the door sections. • End panel assemblies •...
- Page 14 CLEARSPAN GARAGES ™ ATTACH END PANEL ASSEMBLIES (continued) INSTALL SIDE RATCHETS 5. Continue attaching the end panel by working evenly The main cover is secured to the shelter frame using down both sides of the rafter toward the base frame ratchets and straps.
- Page 15 CLEARSPAN GARAGES ™ INSTALL SIDE RATCHETS (continued) 5. Repeat the previous step for all remaining ratchets to attach them to the end panel conduits as previously 3. Repeat previous step to attach the remaining ratchets described and shown. to the outside of the base frame tube.
- Page 16 CLEARSPAN GARAGES ™ INSTALL MAIN COVER (continued) 7. Toss the ropes over the frame and pull the cover into position. One person is required at each rope. 2. After assembling the cover conduits, locate the main 8. Center the cover front to back and side to side.
-
Page 17: Care And Maintenance
If the shelter is moved, inspect all parts and connections before using. • For replacement or missing parts, call 1.800.245.9881 for assistance. NOTE: With the exception of Truss Arch buildings, ClearSpan™ shelters and greenhouses do not have any tested loading criteria. Revision date: 09.14.10... - Page 18 CLEARSPAN GARAGES ™ 12'-2" Height 9'-6" QUICK START GUIDE Sidewall 12' Wide Storage Master Elite Garage 12'-0" Width FRONT Grid Represents 12" Squares Actual frame may differ in length from frame shown. Revision date: 09.14.10...
- Page 19 CLEARSPAN GARAGES ™ Revision date: 09.14.10...
- Page 20 CLEARSPAN GARAGES ™ Revision date: 09.14.10...
- Page 21 CLEARSPAN GARAGES ™ Revision date: 09.14.10...
- Page 22 CLEARSPAN GARAGES ™ Revision date: 09.14.10...
- Page 23 CLEARSPAN GARAGES ™ Revision date: 09.14.10...
