©2016 ClearSpan™
All Rights Reserved. Reproduction
is prohibited without permission.
Revision date: 05.20.16
ClearSpan
Storage Master Elite Garages
30' Wide
Photo shows a different but similar model.
™
STK#
DIMENSIONS
107771
30' W x 15' H x 24' L
107772
30' W x 15' H x 28' L
107773
30' W x 15' H x 36' L
107774
30' W x 15' H x 44' L
CLEARSPAN
GARAGES
™
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 107771 and is the answer not in the manual?

Questions and answers

Related Manuals for ClearSpan 107771

Summary of Contents for ClearSpan 107771

  • Page 1 Storage Master Elite Garages 30' Wide Photo shows a different but similar model. STK# DIMENSIONS 107771 30' W x 15' H x 24' L 107772 30' W x 15' H x 28' L 107773 30' W x 15' H x 36' L ©2016 ClearSpan™...

  • Page 2: Safety Precautions

    READ THIS DOCUMENT BEFORE YOU BEGIN • Never erect the structure under power lines. Thank you for purchasing this ClearSpan™ shelter. When • Identify whether underground cables and pipes are properly assembled and maintained, this product will present before preparing the site or anchoring the provide years of reliable service.

  • Page 3: Assembly Procedure

    These words and phrases are common to most straight ends of other pipes. ClearSpan™ shelters and identify the different parts of the • Tek Screw: A self-tapping fastener used to secure pipe shelter.

  • Page 4: Required Tools

    CLEARSPAN GARAGES ™ REQUIRED TOOLS ANCHORING INSTRUCTIONS The following list identifies the main tools needed to Prior to assembling this shelter, please read the MUST assemble the shelter. Additional tools and supports may be READ document included with the shipment.
  • Page 5 CLEARSPAN GARAGES ™ The following graphics and photos will help identify the different parts used to construct your shelter. (Some parts are not shown.) FA4482B 100441 QH1070 102921 Tek Screw Nut Setter Pipe Strap Neo-Bonded Washer 105088 105087 QH1330 FAG363B 3/8" Bolt...
  • Page 6 CLEARSPAN GARAGES ™ ClearSpan Storage Master ™ Elite Garage OVERVIEW This section describes assembling the garage frame. See illustration below to identify main parts of shelter. 1. Locate required parts for each assembly procedure. 2. Assemble and position base rails.
  • Page 7 CLEARSPAN GARAGES ™ LAY OUT THE BUILDING SITE ASSEMBLE AND POSITION BASE RAILS After the site is prepared, marking the ground where the NOTE: Assistance is required to assemble the garage shelter will be situated and identifying the location of frame.
  • Page 8 CLEARSPAN GARAGES ™ ASSEMBLE AND POSITION BASE RAILS (Continued) Attach 105088 1-Way Connector (Rafter Feet) 5. Position base rails on the site where the shelter will be assembled. Space rails at the approximate width of the Gather parts: shelter. •...

  • Page 9: Rafter Assembly

    CLEARSPAN GARAGES ™ RAFTER ASSEMBLY 3. Secure each pipe joint using two Tek screws. Verify that Gather parts: the screws are driven through the outer rafter pipe and into the swaged section of the inserted rafter pipe. • Rafter pipes: 24CP23P3 and 24CP23P1 •...
  • Page 10 CLEARSPAN GARAGES ™ RAFTER ASSEMBLY (continued) 9. Position cross support assembly between rafter legs 6. Once rafter tubes for first rafter are assembled and with channel facing up and toward rafter. pipe straps (QH1070) are attached to underside of the rafter tubes, attach cross support.
  • Page 11 CLEARSPAN GARAGES ™ 15. Take one S20P030 square tube, set one end inside the 22. Using Tek screws, the 100441 nut setter, and a drill, cross support and align the tube with the 7/16" holes. secure plate to rafter and diagonal brace.

  • Page 12: Frame Assembly

    CLEARSPAN GARAGES ™ FRAME ASSEMBLY 3. Secure rafter leg tubes to each 105088 connector The following instructions assume the rafter feet (105088) using two Tek screws. Position screws so they "drill" are properly spaced on base rails as previously instructed into each connector secured to the base rail.
  • Page 13 CLEARSPAN GARAGES ™ FRAME ASSEMBLY (continued) ATTENTION: Typically purlin pipes do not need cut. 9. Measure between rafter peaks, verify that the on-center Verify that you have selected the correct pipe to end dimension is forty-eight inches (48"), and tighten pipe strap Tek screws on second rafter.
  • Page 14 CLEARSPAN GARAGES ™ SQUARE THE ASSEMBLED FRAME The diagrams below illustrate two possible ways to properly anchor the shelter to the site. Sample frame shown below Complete these steps: may differ from the actual frame. 1. Square the frame by measuring diagonally (corner- to-corner) at the base and verify that the two measurements are equal.
  • Page 15 CLEARSPAN GARAGES ™ SIDE STRUT INSTALLATION INSTALL SHELTER BRACING Gather parts: The diagonal bracing is installed after the frame is squared and anchored and before installing the end panels and • 8' struts (105119) and Tek screws main cover. Complete these steps to install the four (4) side struts: Gather parts: 1.
  • Page 16 CLEARSPAN GARAGES ™ END CONDUITS ASSEMBLY INSTALL END PANELS Gather parts: After anchoring the shelter, install the end panels. Both end panels are secured to the end rafters using Tek screws and • Pipe 1.315'' x 73.5'' plain and 1.315'' x 75'' swaged neo-bonded washers.
  • Page 17 CLEARSPAN GARAGES ™ INSTALL END PANELS (CONTINUED) 4. Rotate the angled bracket and attach it to the base 7. Pull the end panel up and over the top of the end rafter and hold it in position. rail as shown in the diagram below. Use FA4482 Tek screws to secure bracket to base rail.
  • Page 18 CLEARSPAN GARAGES ™ INSTALL END PANELS (CONTINUED) 9. After securing the lower section of the end panel to Space below is reserved for customer notes. the end rafter, stretch the panel over the top to remove wrinkles, and secure it in place as previously described.
  • Page 19 CLEARSPAN GARAGES ™ PREPARE MAIN COVER Gather parts: 4. After assembling the cover conduits, take the main cover and unfold it on a clean, smooth surface near the • Ratchets (1"), main cover, and Tek screws frame. • 1.315" x 75" swaged pipe (131S075) NOTE: Unfold the main cover with the inside surface •...
  • Page 20 CLEARSPAN GARAGES ™ ATTACH MAIN COVER Gather parts: 4. Once the main cover is pulled into position, center • Main cover (with conduits already inserted) the cover on the frame and loosely secure the ends of the cover to the ratchets attached to the end panel •...

  • Page 21: Care And Maintenance

    • For replacement or missing parts, call 1.800.245.9881 for assistance. 9. Repeat the steps for the remaining ratchets. NOTE: With the exception of Truss Arch buildings, ClearSpan™ shelters and greenhouses do not have any tested loading criteria. Revision date: 05.20.16...
  • Page 22 CLEARSPAN GARAGES ™ QUICK START GUIDE 30' Wide Garage 15'3 3/4" Height 9'6 1/8" Sidewall Height 30'0" Width FRONT Grid Represents 12" Squares Shelter shown above may be of a different length than actual shelter. Revision date: 05.20.16...
  • Page 23 CLEARSPAN GARAGES ™ Revision date: 05.20.16...
  • Page 24 CLEARSPAN GARAGES ™ Revision date: 05.20.16...
  • Page 25 CLEARSPAN GARAGES ™ Revision date: 05.20.16...
  • Page 26 CLEARSPAN GARAGES ™ Revision date: 05.20.16...
  • Page 27 CLEARSPAN GARAGES ™ Revision date: 05.20.16...
  • Page 28 CLEARSPAN GARAGES ™ Revision date: 05.20.16...
  • Page 29 CLEARSPAN GARAGES ™ Revision date: 05.20.16...
