ClearSpan Jubilee Frame Tent Assembly Instructions Manual

Advertisement

Quick Links

©2008 ClearSpan™
All Rights Reserved. Reproduction
is prohibited without permission.
Revision date: 05.19.09
ClearSpan
Jubilee Frame Tent
Photo may show a different but similar model.
CLEARSPAN
STK#
DIMENSION
103942 & 104514
30' Wide x 45' Long
JUBILEE TENTS
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Jubilee Frame Tent and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for ClearSpan Jubilee Frame Tent

  • Page 1 CLEARSPAN JUBILEE TENTS ™ ClearSpan ™ Jubilee Frame Tent Photo may show a different but similar model. STK# DIMENSION ©2008 ClearSpan™ 103942 & 104514 30' Wide x 45' Long All Rights Reserved. Reproduction is prohibited without permission. Revision date: 05.19.09...
  • Page 2: Safety Precautions

    • Never erect the structure under power lines. • Identify whether underground cables and pipes are Thank you for purchasing this ClearSpan™ shelter. When present before preparing the site or anchoring the properly assembled and maintained, this product will structure.
  • Page 3: Assembly Procedure

    These words and phrases are common to most ends of a pipe can be inserted into couplers and the ClearSpan™ shelters and identify the different parts of straight ends of other pipes of the same diameter. the shelter. (Some are used in this document. Others may •...
  • Page 4: Required Tools

    CLEARSPAN JUBILEE TENTS ™ REQUIRED TOOLS SPECIAL NOTE: Baseboards for Frame The following list identifies the main tools needed to These instructions recommend installing a baseboard assemble the shelter. Additional tools and supports may be under the legs of the frame. The baseboard runs from the needed depending on the structure, location, and front to the back of the building.
  • Page 5 CLEARSPAN JUBILEE TENTS ™ The following graphics and photos will help you identify the different parts of the building. Consult the Frame Overview for additional details and diagrams. (Some parts are not shown.) FA4482B FAH007B & FALB01B 100441 Tek Screw...
  • Page 6 Photo may show a different but similar model. OVERVIEW This section describes assembling your jubilee frame tent. For details of each assembly procedure, consult the Frame Overview and the individual sections of these instructions. See illustration below to identify main parts of shelter.
  • Page 7 CLEARSPAN JUBILEE TENTS ™ LAY OUT THE BUILDING SITE NOTE: Setting customer-supplied baseboards on the site in the correct positions is another way to prepare After the site is prepared, identify the location of the shelter for the frame assembly.
  • Page 8: Frame Assembly

    CLEARSPAN JUBILEE TENTS ™ ASSEMBLE THE JUBILEE TENT COMPONENTS FRAME ASSEMBLY NOTE: Assistance is required to assemble the tent. Gather the parts: • All rafter assemblies RAFTER ASSEMBLY • Leg pipe (#190P094D) Gather the parts: • Crown Coupler (#103931) •...
  • Page 9 CLEARSPAN JUBILEE TENTS ™ FRAME ASSEMBLY (continued) Crown Coupler Step 1: Assemble Top Ridge a. Slide two (2) short tee swivels onto a base rafter (171") as shown in picture below. b. Secure each end of the rafter to a crown coupler as shown in the diagram to the right.
  • Page 10 CLEARSPAN JUBILEE TENTS ™ FRAME ASSEMBLY (continued) OVERVIEW Step 3: Assemble Mid Section a. Connect two side rafters (191") and two base rafters (171"). NOTE: Slide the base rafters through the short tee swivels before connecting to the side couplers.
  • Page 11: Top View

    CLEARSPAN JUBILEE TENTS ™ FRAME ASSEMBLY (continued) OVERVIEW Step 4: Assemble Side Rafters a. Connect the remaining side rafters (191") to the crown couplers. b. Connect a side coupler to the free end of each rafter. c. Secure each connection with a carriage bolt and nut.
  • Page 12 CLEARSPAN JUBILEE TENTS ™ FRAME ASSEMBLY (continued) OVERVIEW Step 5: Assemble Base Rafters a. Connect the base rafters (171") and corner couplers. b. Secure each connection with a carriage bolt and nut. Dashed line shows assembly section. TOP VIEW Base Rafters...
  • Page 13 CLEARSPAN JUBILEE TENTS ™ FRAME ASSEMBLY (continued) Step 6: Assemble Corner-to-Crown Coupler Hip Rafters a. Connect all hip rafters (126") and hip couplers as shown in the diagram. b. Verify that bolts are properly positioned and tight. TOP VIEW Corner...
  • Page 14 CLEARSPAN JUBILEE TENTS ™ FRAME ASSEMBLY (continued) TOP VIEW Step 7: Assemble Side Coupler-to-Side Coupler Hip Rafters ATTENTION: Frame will be tight in these areas. The circled hip rafters will have to be assembled differently. a. Take the hip rafter pipe apart and connect the...
  • Page 15 CLEARSPAN JUBILEE TENTS ™ FRAME ASSEMBLY (continued) 5. With all legs installed, lift each leg pipe and slip the Leg and Lower Base Assembly appropriate short cross or 3-way open corner onto the leg pipe. See the diagram that follows for details.
  • Page 16 CLEARSPAN JUBILEE TENTS ™ FRAME ASSEMBLY (continued) ANCHOR THE FRAME Once the frame is anchored properly, continue with these 7. Beginning at a corner, slide each lower base rafter instructions. (178 1/2") into place as they are positioned in the...
  • Page 17 CLEARSPAN JUBILEE TENTS ™ PREPARE MAIN COVER Pull rope to remove excess slack and tie off. Gather the parts: 7. Repeat Steps 5 and 6 for the remaining three sides. • Cover NOTE: To keep cover centered, install all ropes before the cover is fully tightened.
  • Page 18 For replacement or missing parts, call 1.800.245.9881 for assistance. NOTE: With the exception of Truss Arch buildings, ClearSpan™ shelters do not have any tested loading criteria. NOTE: A space will remain between the cover edge and the frame as shown in the diagrams.
  • Page 19 CLEARSPAN JUBILEE TENTS ™ FULL FRAME TOP VIEW Base Rafter Base Rafter Hip Coupler Hip Coupler Side Rafter Side Rafter Mid Rafter Mid Rafter Side Rafter Side Rafter Hip Coupler Hip Coupler Base Rafter Base Rafter Side Coupler Revision date: 05.19.09...
  • Page 20 CLEARSPAN JUBILEE TENTS ™ LOWER BASE TOP VIEW Revision date: 05.19.09...
  • Page 21 CLEARSPAN JUBILEE TENTS ™ Space below is reserved for customer notes. Revision date: 05.19.09...
