  • Page 1 nxp/c frequency converters user's manual...
  • Page 2 Follow the commissioning instructions, see Chapter 9. 10. The Vacon NX_ Frequency Converter is now ready for use. Vacon Plc is not responsible for the use of the frequency converters against the instructions. 24-hour support: +358 (0)40 837 1150 • Email: vacon@vacon.com...
  • Page 3 2 • vacon CONTENTS VACON NXC USER’S MANUAL INDEX SAFETY INTRODUCTION RECEIPT OF DELIVERY TECHNICAL DATA MOUNTING CABLING AND CONNECTIONS INSTALLATION INSTRUCTIONS CONTROL KEYPAD COMMISSIONING FAULT TRACING Tel. +358 (0)201 2121 • Fax +358 (0)201 212 205...

  • Page 4: Table Of Contents

    Storage............................12 Maintenance ..........................12 Warranty ............................12 TECHNICAL DATA...........................13 Power ratings ..........................13 4.1.1 Vacon NXP/C 5 – Mains voltage 380—500 V ................13 4.1.2 Vacon NXP/C 6 – Mains voltage 525—690 V ................14 Technical data..........................15 MOUNTING .............................17 Dimensions ............................17 Lifting the unit out of the transport packaging................18 Fixing the unit to the floor or to the wall ..................18...
  • Page 5 4 • vacon 6.2.3 Control cable ..........................32 6.2.4 Cable and fuse sizes, 380-500V units ..................32 6.2.5 Cable and fuse sizes, 525-690V units ..................34 INSTALLATION INSTRUCTIONS......................36 Cable installation and the UL standards ..................37 7.1.1 Cable and motor insulation checks ..................38 Control unit ............................39 7.2.1 Control connections ........................40...

  • Page 6: Safety

    Vacon NX is disconnected from mains. Before connecting the frequency converter to mains make sure that the Vacon NX front and cable covers as well as the cabinet doors are closed. 24-hour support: +358 (0)40 837 1150 • Email: vacon@vacon.com...

  • Page 7: Earthing And Earth Fault Protection

    SAFETY Earthing and earth fault protection The Vacon NX frequency converter must always be earthed with an earthing conductor connected to the PE bar in the lower front side of the cabinet. The earth fault protection inside the frequency converter protects only the converter itself against earth faults in the motor or the motor cable.

  • Page 8: Introduction

    • 7 INTRODUCTION The Vacon NXC is a product range of free standing enclosed frequency converters for the high power range. The NXC is a modular product intended for use in all applications where reliability and high availability is appreciated.

  • Page 9: Manufacturer's Declaration Of Conformity

    8 • vacon INTRODUCTION Manufacturer's declaration of conformity Below you can find the Manufacturer's Declarations of Conformity assuring the compliance of Vacon NXP/C frequency converters with the EMC-directives. EU DECLARATION OF CONFORMITY Manufacturer's name: Vacon Oyj Manufacturer's address: P.O.Box 25...

  • Page 10: Receipt Of Delivery

    • 9 RECEIPT OF DELIVERY Vacon NX frequency converters have undergone scrupulous tests and quality checks at the factory before they are delivered to the customer. However, after unpacking the product, check that no signs of transport damages are to be found on the product and that the delivery is complete (com- pare the type designation of the product to the code below).

  • Page 11: Nxc Additional Option Codes

    10 • vacon RECEIPT OF DELIVERY NXC additional option codes The NXC enclosure solution contains additional pre-engineered hardware options. These options are appended to the basic type code by using “+” codes. You will find the complete type code on the name plate of the unit.

  • Page 12: Auxiliary Equipment (A-Group)

    DCM Analogue meter + current transformer 48mm, std scale 0-600A DVM Analogue vltg meter with sel.switch 0, L1-L2, L2-L3, L3-L1 3.2.10 UL-area (U-group) UFQ 60Hz Power devices Standard 50/60 Hz UCV 115AC Control devices 24-hour support: +358 (0)40 837 1150 • Email: vacon@vacon.com...

  • Page 13: Storage

    In IP54 units, the air filters in the door and in the roof should be cleaned or replaced regularly. It is recommended to replace the fans every 6 years. We recommend checking the tightening torques of terminals at regular intervals. Vacon Service Centre can provide you with a long-period maintenance plan for your frequency converter on request. Warranty Only manufacturing defects are covered by the warranty.

  • Page 14: Technical Data

    FR14 2806X2275X605/2500 Table 4-1. Power ratings and dimensions of Vacon NX, supply voltage 380—500V. Note: The rated currents in given ambient temperatures are achieved only when the switching fre- quency is equal to or less than the factory default (automatic thermal management).

  • Page 15: Vacon Nxp/C 6 - Mains Voltage 525-690 V

    FR14 2806X2275X605/2500 Table 4-2. Power ratings and dimensions of Vacon NX, supply voltage 525—690V. Note: The rated currents in given ambient temperatures are achieved only when the switching frequency is equal to or less than the factory default (automatic thermal management).

  • Page 16: Technical Data

    (Continues on next page) *The rated currents in given ambient temperatures are achieved only when the switching frequency is equal to or less than the factory default. Thermal management might reduce the switching frequency. 24-hour support: +358 (0)40 837 1150 • Email: vacon@vacon.com...
  • Page 17 16 • vacon TECHNICAL DATA EMC (at default Immunity Fulfils EN61800-3, 2 environment settings) Emissions EMC level L: EN 61800-3 (1996)+A11 (2000)(2 envi- ronment) EMC level T: For IT-networks Safety EN 50178 (1997), EN 60204-1 (1996), EN 60950 (2000, 3rd edition) (as relevant), CE, UL, CUL, FI, GOST R, EN 61800-5;...

  • Page 18: Mounting

    * the option +GPL (Plinth) increases the height by 100mm ** some options, e.g. +CIT (Top input cabling +400mm), +COT (Top output cabling +400mm) and +ODU (output du/dt filter +400mm) affect the width of the cabinet *** contact factory 24-hour support: +358 (0)40 837 1150 • Email: vacon@vacon.com...

  • Page 19: Lifting The Unit Out Of The Transport Packaging

    18 • vacon MOUNTING Lifting the unit out of the transport packaging The unit is delivered either in a wooden box or a wooden cage. The box may be transported either horizontally or vertically, while transportation of the cage in a horizontal position is not allowed. To lift the unit out of the box, use lifting equipment capable of handling the weight of the cabinet.

  • Page 20: Fixing To The Floor And To The Wall

    Fix the cabinet to the floor in the front with bolts and use the fixing brackets in the middle. Fix all cabinet sections in the same way. Figure 5-4. Fixing all for corners to the floor 24-hour support: +358 (0)40 837 1150 • Email: vacon@vacon.com...

  • Page 21: Ac Choke Connections

    MOUNTING AC choke connections The AC input choke carries out several functions in the Vacon NX frequency converter. The input choke is needed as an essential component for motor control, to protect the input and DC-link com- ponents against abrupt changes of current and voltage as well as to function as a protection against harmonics.

  • Page 22: Auxiliary Voltage Transformer Tappings

    Locate the transformer in the lower part of the cabinet. The primary side of the transformer has tappings that correspond to standard main voltages. Change to tapping to correspond to the mains voltage in use. 24-hour support: +358 (0)40 837 1150 • Email: vacon@vacon.com...

  • Page 23: Cooling

    22 • vacon MOUNTING Cooling 5.6.1 Free space around the cabinet Enough space must be left above and in front of the cabinet to ensure sufficient cooling and space for maintenance. The amount of cooling air required is indicated in the table below. Also make sure that the tempera- ture of the cooling air does not exceed the maximum ambient temperature of the converter.

  • Page 24: Power Losses

    For dimensioning of cooling or ventilation equipment for electri- cal rooms the following generic formula gives a good approximation of the heat losses at nominal conditions: [kw] = P [kW] x 0,025 loss 24-hour support: +358 (0)40 837 1150 • Email: vacon@vacon.com...

  • Page 25: Cabling And Connections

    24 • vacon CABLING AND CONNECTIONS CABLING AND CONNECTIONS Understanding the power unit topology Figure 6-1 shows the principles for mains and motor connections of the basic 6-pulse drive in frame sizes FR10 to FR14. Some units built in frame size FR11 have double input devices and require an even number of supply cables but an uneven number of motor cables can be used.

  • Page 26: Power Connections

    Tables 6-2 and 6-4 show the minimum dimensions of Cu- and Al-cables and the recommended aR fuse sizes. If the motor temperature protection of the drive (see Vacon All in One Application Manual) is used as an overload protection, the cable should be chosen accordingly. If three or more cables are used parallelly (per block) in bigger units each cable requires a separate overload protection.
  • Page 27 26 • vacon CABLING AND CONNECTIONS Cable type Level L Level T Level N environment) Mains cable Motor cable 1/2* 1/2* Control cable Table 6-1. Cable types required to meet standards *Recommended Level L = EN61800-3, 2 environment Level T...
  • Page 28 Connect the PE conductor Connect the PE to the PE bar conductors to the PE bar ud1011k9.fh8 Figure 6-4. Routing of power cables, bottom cabling, frame FR13 24-hour support: +358 (0)40 837 1150 • Email: vacon@vacon.com...
  • Page 29 28 • vacon CABLING AND CONNECTIONS Connect motor cables to Connect mains cables to terminals U, V and W on power terminals on the converter converter ud1011k16.fh11 Connect the PE conductors to the PE bar Figure 6-5. Routing of power cables, bottom cabling, frame FR14 6.2.1.1...
  • Page 30 Roll up the sock as far as the fastening ring and remove the cone-shaped tool if used. Now the cable installation is easier and the cable will not damage the sock. Clamp the sock to the shielding of cable with a cable tie. Cone-shaped tool Metal sock Fastening spring 24-hour support: +358 (0)40 837 1150 • Email: vacon@vacon.com...
  • Page 31 30 • vacon CABLING AND CONNECTIONS Tel. +358 (0)201 2121 • Fax +358 (0)201 212 205...
  • Page 32 Vacon's delivery consists of fixed sets of ferrite rings (option). When ferrite rings are used to attenuate the risk of bearing damages, use always two ferrite ring sets per motor cable.

  • Page 33: Dc Supply And Brake Resistor Cables

    6.2.2 DC supply and brake resistor cables Vacon frequency converters can optionally be equipped with terminals for DC supply and with an external brake resistor. These terminals are marked with B-, B+/R+ and R-. The DC bus connection is made to terminals B– and B+ and the brake resistor connection to R+ and R– on the converter module.
  • Page 34 No additional drive fuses Cu: 8*(3*185+95) NX2150 5 2150 Even Even Al: 8*(3*300+88Cu) needed Table 6-2. Cable and fuse sizes for Vacon NX_5, 6-pulse supply based on correction factor 0.7 Mains and motor No. of No. of Fuse I cable supply...

  • Page 35: Cable And Fuse Sizes, 525-690V Units

    No additional drive fuses needed Even Even Al:8*(3*240+72Cu) Cu:8*(3*240+120) NX2250 6 2250 No additional drive fuses needed Even Even Al:8*(3*300+88Cu) Table 6-4. Cable and aR fuse sizes for Vacon NX_6, 6-pulse versions Tel. +358 (0)201 2121 • Fax +358 (0)201 212 205...
  • Page 36 Even Al:8*(3*240+72Cu) Cu:8*(3*240+120) NX2250 6 2250 No additional drive fuses needed Even Even Al:8*(3*300+88Cu) Table 6-5. Cable and aR fuse sizes for Vacon NX_6, 12-pulse versions based on correction factor 0.7 24-hour support: +358 (0)40 837 1150 • Email: vacon@vacon.com...

  • Page 37: Installation Instructions

    36 • vacon INSTALLATION INSTRUCTIONS INSTALLATION INSTRUCTIONS Before starting the installation, check that none of the components of the frequency converter is live. Make sure that the space where the converter is installed, and the con- verter itself, is clean and free from particles, dust or humidity that could harm the converter when it is powered on.

  • Page 38: Cable Installation And The Ul Standards

    (no devices between converter and motor). ** Apply counter torque to the nut on the other side of the terminal when tightening/loosening the terminal screw in order to avoid damage to the terminal. 24-hour support +358 (0)40 837 1150 • Email: vacon@vacon.com...

  • Page 39: Cable And Motor Insulation Checks

    38 • vacon INSTALLATION INSTRUCTIONS 7.1.1 Cable and motor insulation checks 1. Motor cable insulation checks Disconnect the motor cable from terminals U, V and W of the frequency converter and from the motor. Measure the insulation resistance of the motor cable between each phase conductor as well as between each phase conductor and the protective ground conductor.

  • Page 40: Control Unit

    The I/O boards mounted at the factory are indicated in the type code. For more information on the option boards, see Vacon NX option board manual (ud741). The control board can be powered externally (+24V, ±10%) by connecting the external power source to either of the bidirectional terminala #6 or #12, see page 42.

  • Page 41: Control Connections

    40 • vacon INSTALLATION INSTRUCTIONS 7.2.1 Control connections The basic control connections for boards A1 and A2/A3 are shown in Chapter 7.2.2. The signal descriptions are presented in the All in One Application Manual. +10Vref Reference AI1+ (voltage) AI2+ Reference...
  • Page 42 B Control Power Analogue AO1+ board board AO2 - output Digital output RO1/1 RO1/2 RO1/3 RO2/1 RO2/2 U V W RO2/3 TI1+ nk6_1 5 TI1- Figure 7-6. Galvanic isolation barriers 24-hour support +358 (0)40 837 1150 • Email: vacon@vacon.com...

  • Page 43: Control Terminal Signals

    42 • vacon INSTALLATION INSTRUCTIONS 7.2.2 Control terminal signals OPT-A1 Terminal Signal Technical information +10 Vref Reference voltage Maximum current 10 mA AI1+ Analogue input, Selection V or mA with jumper block X1 (see page 45): voltage or current Default: 0– +10V (Ri = 200 kΩ) (-10V…..+10V Joy-stick control, selected with a jumper)
  • Page 44 Positive logic (+24V is the active signal) = Requires setting of jumper X3 to position the input is active when the switch is closed ‘CMA/CMB isolated from ground’ Figure 7-7. Positive/Negative logic 24-hour support +358 (0)40 837 1150 • Email: vacon@vacon.com...
  • Page 45 44 • vacon INSTALLATION INSTRUCTIONS 7.2.2.2 Jumper selections on the OPT-A1 basic board The user is able to customise the functions of the frequency converter to better suit his needs by selecting certain positions for the jumpers on the OPT-A1 board. The positions of the jumpers determine the signal type of analogue and digital inputs.
  • Page 46 AO1 mode: Voltage output; 0...10V = Factory default Figure 7-9. Jumper selection for OPT-A1 If you change the AI/AO signal content also remember to change the corresponding board parameter in menu NOTE 24-hour support +358 (0)40 837 1150 • Email: vacon@vacon.com...

  • Page 47: Control Keypad

    CONTROL KEYPAD CONTROL KEYPAD The control keypad is the link between the Vacon frequency converter and the user. The Vacon NX control keypad features an alphanumeric display with seven indicators for the Run status (RUN, , READY, STOP, ALARM, FAULT) and three indicators for the control place (I/O term/ Keypad/BusComm).

  • Page 48: Control Place Indications

    = Description line; Displays the description of menu, value or fault. ••• = Value line; Displays the numerical and textual values of references, parameters etc. and the number of submenus available in each menu. 24-hour support: +358 (0)40 837 1150 • Email: vacon@vacon.com...

  • Page 49: Keypad Push-Buttons

    48 • vacon CONTROL KEYPAD Keypad push-buttons The Vacon alphanumeric control keypad features 9 push-buttons that are used for the control of the frequency converter (and motor), parameter setting and value monitoring. Figure 8-2. Keypad push-buttons 8.2.1 Button descriptions reset This button is used to reset active faults (see Chapter 8.3.4).

  • Page 50: Navigation On The Control Keypad

    From there you will be able to navigate your way up to the desired menu using the menu and browser buttons. More detailed descriptions of the menus you will find later in this Chapter. 24-hour support: +358 (0)40 837 1150 • Email: vacon@vacon.com...
  • Page 51 50 • vacon CONTROL KEYPAD READY R EADY R EADY I/Oterm I/Ote rm I/Oterm Expander boards A:NXOPTA1 Parameters G1 G5 G1 G1 P1 P3 STOP R EADY STOP R EADY Change I/Ote rm I/Ote rm enter value System Menu Language...

  • Page 52: Monitoring Menu (M1)

    Digital and relay output statuses V1.15 Analogue output V1.16 current Displays three selectable monitoring values. See M1.17 Multimonitoring items chapter 8.3.6.5. Table 8-1. Monitored signals Note: The All in One applications embody more monitoring values. 24-hour support: +358 (0)40 837 1150 • Email: vacon@vacon.com...

  • Page 53: Parameter Menu (M2)

    52 • vacon CONTROL KEYPAD 8.3.2 Parameter menu (M2) Parameters are the way of conveying the commands of the user to the frequency converter. The parameter values can be edited by entering the Parameter Menu from the Main Menu when the location indication M2 is visible on the first line of the display.
  • Page 54 Keypad Parameters Basic parameters Min Frequency P1 P18 G1 G8 13.95 Hz READY READY Keypad Keypad Min Frequency Min Frequency 13.95 Hz enter 14.45 Hz Figure 8-5. Parameter value change procedure 24-hour support: +358 (0)40 837 1150 • Email: vacon@vacon.com...

  • Page 55: Keypad Control Menu (M3)

    54 • vacon CONTROL KEYPAD 8.3.3 Keypad control menu (M3) Keypad Controls Menu In the , you can choose the control place, edit the frequency reference and change the direction of the motor. Enter the submenu level with the Menu button right...
  • Page 56 START button Keypad when the keypad is not selected as the active control place you will get an error message Control NOT ACTIVE 24-hour support: +358 (0)40 837 1150 • Email: vacon@vacon.com...

  • Page 57: Active Faults Menu (M4)

    56 • vacon CONTROL KEYPAD 8.3.4 Active faults menu (M4) Active faults menu Main menu Menu button right can be entered from the by pushing the when the location indication M4 is visible on the first line of the keypad display.
  • Page 58 Real time record If real time is set to run on the frequency converter the data items T1 and T2 will appear as follows: Counted operation days yyyy-mm-dd Counted operation hours hh:mm:ss,sss 24-hour support: +358 (0)40 837 1150 • Email: vacon@vacon.com...

  • Page 59: Fault History Menu (M5)

    58 • vacon CONTROL KEYPAD 8.3.5 Fault history menu (M5) Fault history menu Main menu Menu button right can be entered from the by pushing the when the location indication M5 is visible on the first line of the keypad display. Find the fault codes in Table 10-2.

  • Page 60: System Menu (M6)

    P6.6.2 Operating menu P6.6.3 Timeout time 65535 P6.6.4 Contrast P6.6.5 Backlight time Always 65535 S6.7 Hardware settings Internal brake Not connected P6.7.1 Connected resistor Connected Continuous P6.7.2 Fan control Continuous Temperature 24-hour support: +358 (0)40 837 1150 • Email: vacon@vacon.com...
  • Page 61 60 • vacon CONTROL KEYPAD HMI acknowledg. P6.7.3 5000 timeout HMI number of P6.7.4 retries System S6.8 information S6.8.1 Total counters C6.8.1.1 MWh counter Power On day C6.8.1.2 counter Power On hours C6.8.1.3 hh:mm:ss counter S6.8.2 Trip counters T6.8.2.1 MWh counter Clear T6.8.2.2...
  • Page 62 CONTROL KEYPAD vacon • 61 8.3.6.1 Language selection The Vacon control keypad offers you the possibility to control the frequency converter through the keypad in the language of your choice. System menu Locate the language selection page under the . Its location indication is S6.1. Press the Menu button right once to enter the edit mode.
  • Page 63 The parameter copy menu (S6.3) embodies four functions: Parameter sets (S6.3.1) The Vacon NX frequency converter features a possibility for the user to load back the factory default parameter values and to store and load two customised parameter sets (all parameters included in the application).
  • Page 64 . Wait until 'OK' appears on the display. The procedure to download the parameters from keypad to drive is similar to that of from drive to keypad. See above. 24-hour support: +358 (0)40 837 1150 • Email: vacon@vacon.com...
  • Page 65 . Choose with the When the Parameter backup function is activated Vacon NX control keypad makes a copy of the parameters of the presently used application. Every time a parameter is changed the keypad backup is automatically updated.
  • Page 66 Password Password Password Not in use Figure 8-14. Password setting Note! Store the password in a secure location! No changes can be made unless a valid password is entered! 24-hour support: +358 (0)40 837 1150 • Email: vacon@vacon.com...
  • Page 67 66 • vacon CONTROL KEYPAD Parameter lock (P6.5.2) This function allows the user to prohibit changes to the parameters. *locked* If the parameter lock is activated the text will appear on the display if you try to edit a parameter value.
  • Page 68 CONTROL KEYPAD vacon • 67 Multimonitoring items (P6.5.4) Vacon alpha-numeric keypad features a display where you can monitor even three actual values at Monitoring values the same time (see chapter 8.3.1 and chapter in the manual of the application you are using).
  • Page 69 68 • vacon CONTROL KEYPAD Default page in the operating menu (P6.6.2) Here you can set the location (page) in the Operating menu (in special applications only) to which Timeout time the display automatically moves as the set (see below) has expired or as the power is switched on to the keypad.
  • Page 70 If the frequency converter has been connected to the PC via a modem and there is delay in transferring messages, the value of par. 6.7.3 must be set according to the delay as follows: 24-hour support: +358 (0)40 837 1150 • Email: vacon@vacon.com...
  • Page 71 70 • vacon CONTROL KEYPAD Example: • Transfer delay between the frequency converter and the PC = 600 ms • The value of par. 6.7.3 is set to 1200 ms (2 x 600, sending delay + receiving delay) • The corresponding setting shall be entered in the [Misc]-part of the file NCDrive.ini:...
  • Page 72 Page Content 6.8.3.1 Software package 6.8.3.2 System software version 6.8.3.3 Firmware interface 6.8.3.4 System load Table 8-8. Software information pages 24-hour support: +358 (0)40 837 1150 • Email: vacon@vacon.com...
  • Page 73 72 • vacon CONTROL KEYPAD Applications (S6.8.4) At location S6.8.4 you can find the Applications submenu containing information about not only the application currently in use but also all other applications loaded into the frequency converter. The information available is:...
  • Page 74 A:NXOPTA1 State E1 E5 E1 E2 Figure 8-26. Expander board information menus Debug menu (S6.8.7) This menu is meant for advanced users and application designers. Contact factory for any assistance needed. 24-hour support: +358 (0)40 837 1150 • Email: vacon@vacon.com...

  • Page 75: Expander Board Menu (M7)

    I/Oterm Baud rate Auto Figure 8-27. Expander board information menu Further keypad functions The Vacon NX control keypad embodies additional application-related functions. See Vacon NX Application Package for more information. Tel. +358 (0)201 2121 • Fax +358 (0)201 212 205...

  • Page 76: Commissioning

    The motor terminals U, V, W and the DC-link/brake resistor terminals –/+ are live when Vacon NX is connected to mains, even if the motor is not running. The control I/O-terminals are isolated from the mains potential. How- ever, the relay outputs and other I/O-terminals may have a dangerous control voltage present even when Vacon NX is disconnected from mains.
  • Page 77 76 • vacon COMMISSIONING Set the parameters of group 1 (See Vacon All in One Application Manual) according to the requirements of your application. At least the following parameters should be set: motor nominal voltage motor nominal frequency motor nominal speed motor nominal current You will find the values needed for the parameters on the motor rating plate.
  • Page 78 Connect the motor to the process (if the startup test was run without the motor being connected) a) Before running the tests, make sure that this can be done safely. b) Inform your co-workers of the tests. c) Repeat test 8A or 8B. 24-hour support: +358 (0)40 837 1150 • Email: vacon@vacon.com...

  • Page 79: Fault Tracing

    78 • vacon FAULT TRACING FAULT TRACING The fault codes, their causes and correcting actions are presented in Table 10-2 below. The converter has an internal memory for storing the converter status at the time of fault as well as additional information about the source of the fault.

  • Page 80: 10.2 Fault Codes

    Time hh:mm:ss, Note: When contacting your Vacon partner because of a fault condition, always write down all texts and codes on the keypad display before. 10.2 Fault codes The fault codes, their causes and correcting actions are presented in the table below. The shadowed faults are A faults only.
  • Page 81 80 • vacon FAULT TRACING System fault component failure Reset the fault and restart. faulty operation Should the fault re-occur, contact your Note exceptional fault data record local distributor. Please visit: Subcode in T.14: http://www.vacon.com/wwcontacts.html S1 = Feedback of motor voltage...
  • Page 82 S4 = Software and ctrl unit incompatible S5 = Old control board version IGBT temperature IGBT Inverter Bridge overtemperature Check loading. protection has detected too high a short Check motor size. term overload current Brake resistor overtemperature 24-hour support: +358 (0)40 837 1150 • Email: vacon@vacon.com...
  • Page 83 Vacon distributor. Please visit: http://www.vacon.com/wwcontacts.html Slot fault Defective option board or slot Check board and slot. Contact the nearest Vacon distributor. Please visit: http://www.vacon.com/wwcontacts.html PT100 board Temperature limit values set for the Find the cause of temperature rise temp. fault...
  • Page 84 Vaasa Helsinki Vacon Traction Oy Vacon Plc (Head office and production) Vacon Plc Alasniitynkatu 30 Runsorintie 7 Äyritie 12 33700 Tampere 65380 Vaasa 01510 Vantaa telephone: +358 (0)201 2121 firstname.lastname@vacon.com telephone: +358 (0)201 212 600 fax: +358 (0)201 212 710...
