Micromon
To exit the zoom facility, remove the graph cursor by pressing '↵' again. Pressing
the ' ' key will then take you back to the Point Detail screen.
When a graph is displayed on the screen, pressing the '
to a directly connected printer (cursor must be removed first).
When one or more alarms have been raised, the built-in siren will sound, the
backlight will flash red and the point(s) in alarm will pulse. If a parallel printer is
connected, the time, status and point details of the alarm can be printed.
If the ' ' key is not pressed within the programmed time setting, the dial-out relay
can be programmed to automatically activate, sending a signal to the dial-out
equipment/security system if it is connected.
To stop the siren sounding and the red backlight flashing, press the '
Check what the problem is by selecting the Point Detail screen for the point in
alarm and noting its present status and alarm settings. The fault will need to be
found and rectified before the alarm can be successfully cleared.
If there appears to be no problem, it could be that the fault has 'cleared itself' (e.g.
the temperature has since returned to an acceptable level). In this case, the point
will stop pulsing.
If there are no further faults on other points, the alarm status will be cleared.
To display the Main Menu, press the '
option from the Main Menu, use the '
required option and press '↵ ↵ ↵ ↵ ↵ ' or ' '.
Note: Options which have a symbol
Use this option to display the default Point Overview screen as previously
described.
To display the alarm history, select the Alarm History option from the Main Menu.
The Alarm List screen is displayed with the most recent alarm heading the list.
Up to 999 latest alarms can be viewed.
Each alarm is given a number from 1 to 999 (restarting at 1 after the 999th) and is
time and date stamped. The description shows the information relevant to each
point. The two '
continues. The list can be scrolled up and down using the '
'↵ ↵ ↵ ↵ ↵ ' to display events with the alarms.
To display the alarm history for a particular point, select the Point Detail screen,
then press the
all alarms for the selected point only.
To display the event history, select the Event History option from the Main Menu.
The Event List screen is displayed with the most recent event heading the list.
The latest 100 events stored are viewed. The list can be scrolled up and down
using the '
This option starts up the easy setup that is used on initial Micromon setup, as
previously described.
Use this option to display the unit's software and hardware details for reference.
To return to the Main Menu, either wait 1 minute or press any key.
This facility only applies if a parallel printer is directly connected. A series of
printouts can be initiated in condensed mode. To perform a print operation press
the ' ' key to display the Print Menu.
RS.8A.Y3.02
Micromon
' or '
' symbols at the bottom of the screen indicate that the list
and keys together. The Alarm List screen is displayed listing
' or ' ' keys.
© Danfoss 01-2003
' key dumps the graph
' key (repeat if necessary). To select an
' key to position the highlight over the
alongside them are password protected.
' or '
' key
.
' keys. Press
