Rectifier - Huawei TP48200A-D14A1 Telecom Power User Manual

TP48200A-D14A1 Telecom Power
User Manual
Table 3-2 Technical specifications of the fan
Item
Rated voltage
Rated power

3.3 Rectifier

Appearance
The rectifier converts the AC input power into stable -48 V DC power.
Figure 3-6 shows the rectifier.
Figure 3-6 Rectifier appearance
Panel
The rectifier panel provides the run indicator, alarm indicator, and fault indicator. Figure 3-7
shows the rectifier panel. Table 3-3 shows the indicator description.
Figure 3-7 Rectifier panel
(1) Run indicator
Issue 04 (2019-12-20)
(2) Protection indicator
Copyright © Huawei Technologies Co., Ltd.
3 Component Description
Specifications
-48 V DC
34 W
(3) Fault indicator
22
