Fan Assembly; Rectifier - Huawei TP48200A-D17A5-2 Telecom Power User Manual

TP48200A-D17A5-2 Telecom Power
User Manual
Item Power Distribution Specifications
Input system 220 V AC single-phase
AC power 
distribution

DC power 
distribution

Battery circuit Two 1-pole 100 A circuit breakers
breaker

3.3 Fan Assembly

The following figure shows the fan assembly.
Figure 3-4 Fan assembly

3.4 Rectifier

Rectifiers convert AC input into stable DC output.
Issue 04 (2019-12-20)
AC input: one 2-pole 50 A circuit breaker
AC output: two maintenance sockets, one residual protection circuit breaker
BLVD route: two 1-pole 10 A circuit breakers, three 1-pole 16 A circuit breakers, and
one 1-pole 20 A circuit breaker
LLVD route: three 1-pole 20 A circuit breakers and five 1-pole 63 A circuit breakers
