TP48200A-D14A1 Telecom Power
User Manual
Figure 2-2 Typical site power solution

2.3 Features






2.4 Configuration

The TP48200A-D14A1 power system mainly consists of the cabinet, temperature control unit
(TCU), rectifier, power distribution unit (PDU), and monitoring unit.
Table 2-1 Configuration
Item
TP48200A-D14A1
Issue 04 (2019-12-20)
Easy Installation of Modules
The monitoring module (PMU) and rectifier module are hot-swappable, thus facilitating
the installation, saving maintenance time, and reducing the OPEX.
Intelligent Sleep Technology
According to the load power, the power system automatically enables one or more
rectifiers to enter the sleep mode.
Wide Range of AC Input Voltage
The AC input voltage of the system ranges from 90 V AC to 290 V AC phase voltage.
Highly Level Safety Design
The power system complies with the CE standard, the power distribution components
comply with the CE and 3C standards, and the rectifier complies with the UL, CE, and
TUV standards.
Copyright © Huawei Technologies Co., Ltd.
Composition
 PMU02C1
 UIM02A
 R4850G1
 PDU
2 Overview
AC input mode
Single phase three
wire
16
