TP48200A-D14A1 Telecom Power
User Manual
Port Type
Analog value detection
Boolean value
detection port
Dry contact output port
Power electronic
manufacturing
information
Issue 04 (2019-12-20)
Silk Screen
GATE
SMOKE
WATER
TEMHUM
AIN
DIN1
DIN2
DIN3
DIN4
DIN5
DIN6
DIN7
ALM1
ALM2
ALM3
ALM4
ALM5
ALM6
ALM7
ALM8
ALM9
PELU
The relate definition of dry contact output port is a default value; it can be set based on customer
requirements.
Copyright © Huawei Technologies Co., Ltd.
Description
Used by the door status sensor
Used by the smoke detector
Used by the water detector
Used by the environment temperature humidity sensor
Used for detecting the battery status
Used for inputting Boolean value 1
Used for inputting Boolean value 2
Used for detecting AC SPD faults
Used for detecting DC SPD faults
Used for inputting Boolean value 5
Used for inputting Boolean value 6
Used for inputting Boolean value 7
Used for reporting smoke alarms
Used for reporting door broken alarms
Used for reporting rectifier faults and rectifier communication
faults
Used for reporting load fuse blown alarms and battery fuse
blown alarms and battery stolen alarms
Used for reporting battery temperature alarms and ambient
temperature alarms
Used for reporting TCU alarms
Used for reporting mains failure alarms
PMU failure alarms
Used for reporting SPD fault alarms
Used for displaying electronic manufacturing information about
the power system
6 Monitoring Function
41
