PanCam Physical Description
The following figure describes both units.
Speaker
Camera
Key-pad
Micro-
phone
PanCam-C
Figure 2-1. PanCam Front Panel
The front panel of the PanCam-T unit incorporates a speaker
and a Call button. The microphone can be found at the bottom
of the unit. The PanCam-C unit also features a keypad. The
front panel is attached to the wall using a bracket and screws.
The PanCam units are hardwired units, powered by an external
12V AC transformer, included in the package.
Optionally, you may use a 12-24V DC adapter.
PanCam/Pantel/Pancode Installation and Programming Manual
Introduction
Call
button
PanCam-T
3
