Specifications

4.1

General Specifications

Power Supply (External)
Line Voltage
DC Leakage
On-Hook Insulation
(Resistance Between Line
Terminal and Ground)
Ring Capacitor
On-Hook Impedance
Ring Detect
DC Resistance (Off-Hook)
Impedance (Off-Hook)
Imbalance Ratio
Return Loss
Current During Break
DTMF Transmission:
Frequency Tolerance
Frequency Level (High)
Frequency Level (Low)
Inter-Digit Pause Time
Relay Switching Current
Dimensions
Outdoor Unit
Indoor Unit
Operating Temperature
PanCam/Pantel/Pancode Installation and Programming Manual
12V AC@1.6A (supplied with unit)
12-24V DC@1.6A (optional)
24-72V DC
< 10 µA
0-100V DC > 5MΩ
100-200 V DC > 30 KΩ
500V AC/50Hz > 20KΩ
100V AC/25Hz > 100KΩ
0.47 µF ±10%
@50V DC, 40V AC/25Hz>3000Ω
27-100 V AC/16-60 Hz
24-66V DC @ 20-100mA/350Ω
300-3400Hz 500-700Ω
300-3400Hz > 46dB
300-3400Hz > 18dB
< 700 µA
±1.5%
-6 to –8dBm
-8 to –10dBm
70-80ms
2A max
19.4cm x 10.2cm/7.6inch x 4.0inch
18.5cm x 9.5cm/7.3inch x 9.5inch
Outdoor: -20ºC to +50ºC/4ºF to
122ºF
Indoor: 0ºC to +35ºC/32ºF to 95ºF
