Table 10. STM32F746G-DISCO IO assignment (continued)
Pin Name
PJ6
PD15
PB13
PD10
PF10
PF9
PF8
PC3
BYPASS_REG
VSS
VDD
VDD
VDD
VDD
VCAP_1
PD14
PB12
PD9
PD8
VSSA
PC0
PC1
PC2
PB2/BOOT1
PF12
PG1
PF15
PJ4
PD12
PD13
PG3
PG2
PJ5
PH12
VREF-
DocID027942 Rev 3
STM32F746G-DISCO IO assignment
Signal or Label
LTDC_R7
FMC_D1_DA1
USB_OTG_HS_ULPI_D6
FMC_D15_DA15
ARDUINO A1
ARDUINO A2
ARDUINO A3
FMC_SDCKE0
-
-
-
-
-
-
-
FMC_D0_DA0
USB_OTG_HS_ULPI_D5
FMC_D14_DA14
FMC_D13_DA13
-
USB_OTG_HS_ULPI_STP
ETH_MDC
USB_OTG_HS_ULPI_DIR
QUADSPI_CLK
FMC_A6
FMC_A11
FMC_A9
LTDC_R5
QUADSPI_BK1_IO1
QUADSPI_BK1_IO3
EXT_RST
RMII_RXER
LTDC_R6
DCMI_D3
-
Comment
-
-
-
-
-
-
-
-
Connected to PD R20
-
-
-
-
-
Connected to C47
-
-
-
-
Connected to GND
-
-
-
-
-
-
-
-
-
-
-
-
-
-
Connected to GND
