STM32F746G-DISCO IO assignment
Pin No.
H1
H2
H3
H4
H5
H6
H10
H11
H12
H13
H14
H15
J1
J2
J3
J4
J5
J6
J10
J11
J12
J13
J14
J15
K1
K2
K3
K4
K5
K6
K7
K8
K9
K10
K11
42/49
Table 10. STM32F746G-DISCO IO assignment (continued)
Pin Name
PH1/OSC_OUT
PF3
PI14
PH4
VDD
VSS
VSS
VDD
PJ8
PJ10
PG8
PC6
NRST
PF4
PH5
PH3
VDD
VSS
VSS
VDD
PJ7
PJ9
PG7
PG6
PF7
PF6
PF5
PH2
VDD
VSS
VSS
VSS
VSS
VSS
VDD
DocID027942 Rev 3
Signal or Label
RCC_OSC_OUT
FMC_A3
LTDC_CLK
USB_OTG_HS_ULPI_NXT
-
-
-
-
LTDC_G1
LTDC_G3
FMC_SDCLK
ARDUINO TX/D1
-
FMC_A4
FMC_SDNWE
FMC_SDNE0
-
-
-
-
LTDC_G0
LTDC_G2
ARDUINO D4
ARDUINO D2
ARDUINO A4
ARDUINO A5
FMC_A5
NC2
-
-
-
-
-
-
-
UM1907
Comment
-
-
-
-
-
-
-
-
-
-
-
-
Hardware RESET
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
