UM1907
Pin number
1
2
3
4
5
6
7.6

USB OTG FS micro-AB connector CN13

Pin number

Table 5. RJ45 connector CN9

Description
A, yellow LED
K, yellow LED
TD+
TD-
CT, 3V3
CT, 3V3

Figure 17. USB OTG micro-AB connector CN13 (front view)

Table 6. USB OTG FS micro-AB connector CN13

Description
1 VBUS (PA9)
2 D- (PA11)
3 D+ (PA12)
DocID027942 Rev 3
Pin number
7
8
9
10
11
12
Pin number
4
5
-
Connectors
Description
RD+
RD-
NC
GND
K, green LED
A, green LED
Description
ID (PA10)
GND
-
23/49
