Turn the Desk Mount over and use one of the M3 Hex Keys
4.
to insert four Hex Screws through the C-Clamp and into the
base of the Mount.
Attaching the Hex Screws to the C-Clamp
Remove the backing from the EVA Cushion.
5.
Align the adhesive side of the EVA Cushion with the bottom
6.
of the Support Pole.
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Assembling the C-Clamp
15
