  • Page 1 Operating and installation instruction REMKO PGM (E) series Propane gas heating systems PGM 30 (E), PGM 60 (E) This product is not suitable as a main heater. Edition GB - Q04 Read the instructions prior to performing any task!
  • Page 3: Table Of Contents

    Contents Safety notes Unit description Installation instructions Gas connection Commissioning 9-10 Shutdown Care and maintenance 11-12 Troubleshooting Intended use Customer service and guarantee Environmental protection and recycling Exploded view of PGM 30 Spare parts list for PGM 30 Exploded view of PGM 60 Replacement parts list for PGM 60 Maintenance protocol Technical data...
  • Page 4: Safety Notes

    REMKO PGM (E) series Safety notes Always observe the respective local building code and fire prevention guidelines as well as the guidelines of the accident prevention and insurance associations when using the units. The units have been subjected by exhaust gases and radiant The air intake grille must always ■...
  • Page 5: Unit Description

    Unit description The units are mobile fan-assisted Operating sequence Monitoring the units air heaters (WLE) directly fired with liquid gas, without a heat After switching on the units, It is possible to safely monitor all exchanger. the supply air fan is put into functions with the safety devices operation and the electric solenoid of the units.
  • Page 6: Installation Instructions

    REMKO PGM (E) series Installation instructions The safety regulations The fresh air supply required ■ CAUTION for trouble-free combustion of the accident prevention For use in public buildings, must be ensured. It is practical and insurance associations, national regulations must...
  • Page 7: Gas Connection

    Gas connection The gas connection / unit CAUTION operation must take place All common gas cylinder sizes ■ Before all work on the gas exclusively on the basis of are permitted for the gas supply and when replacing the accident prevention regulation supply.
  • Page 8 REMKO PGM (E) series Connecting the gas supply Assembly note Icing up of gas cylinders 1. Connect pressure With insufficiently dimensioned During the assembly or controller gas supply systems, there is a risk disassembly of the gas hose, it is...
  • Page 9: Commissioning

    Commissioning Tank gas systems The units should be checked for Connecting the units visible defects on the operating to the electrical power supply When connecting the units to tank and safety devices as well as gas systems, ensure sufficient pipe proper installation and correct 1.
  • Page 10 REMKO PGM (E) series Heating mode Setting and controlling Ventilate the heating capacity 1. Move the operating In this operating mode, the supply switch to the "I" position. The desired or required heating air fan runs permanently. The supply air fan starts...
  • Page 11: Shutdown

    Shutdown Care and maintenance 1. Close the shut off valve(s) Check the inlet and outlet grille ■ NOTE of the gas supply system and for contamination on a regular Regular care and maintenance, allow the gas flame to burn out. basis at the latest after every heating period, is the basic...
  • Page 12 REMKO PGM (E) series Disassembling and cleaning 10. Carefully clean the gas burner Gas burner the gas burner with a suitable brush and possibly compressed air. 1. Switch off the gas supply to the unit and remove the 11. Clean the gas nozzle power plug from the mains if necessary.
  • Page 13: Troubleshooting

    Troubleshooting Malfunctions: Cause: The unit does not start. 1 – 2 – 3 – 4 – 7 The unit switches off during operation. 2 – 4 – 7 – 12 – 13 The fan runs, but the gas supply is blocked 4 –...
  • Page 14: Intended Use

    "certificate of guarantee" Our units are carefully packed to REMKO GmbH & Co. KG at the and delivered in sturdy transport According to DIN EN 1596, the device definition is “warm air time when the units are purchased...
  • Page 16: Exploded View Of Pgm

    REMKO PGM (E) series Exploded view of PGM 30 (E) We reserve the right to modify the dimensions and design as part of the ongoing technical development process.
  • Page 17 Spare parts list No. Description EDP no. 1 Transport handle 1101142 2 Exterior cladding PGM 30 1101405 2a Exterior cladding PGM 30 E 1101477 3 Combustion chamber 1121186 4 Completion panel, front 1101479 5 Protective outlet grille 1101383 6 Safety temperature limiter 1101197 7 Inspection cover 1101385...
  • Page 18: Exploded View Of Pgm

    REMKO PGM (E) series Exploded view of PGM 60 (E) We reserve the right to modify the dimensions and design as part of the ongoing technical development process.
  • Page 19 Spare parts list No. Description EDP no. 1 Transport handle 1101142 2 Exterior cladding PGM 60 1101420 2a Exterior cladding PGM 60 E 1101461 3 Insulation 1101421 4 Combustion chamber 1101422 5 Gas burner 1101423 6 Protective outlet grille 1101424 7 Gas nozzle 1101426 8 Gas supply pipe Z/D...
  • Page 20: Maintenance Protocol

    REMKO PGM (E) series ✍ Maintenance protocol Unit type: ........Unit number: ........10 11 12 13 14 15 16 17 18 19 20 Unit cleaned - outside - Unit cleaned - inside - Fan blade cleaned Combustion chamber cleaned...
  • Page 21: Technical Data

    Technical data Series PGM 30 (E) PGM 60 (E) Nominal heat load max 26.00 55,00 Nominal heat capacity 26.00 55,00 Minimum heat capacity 10.00 25,00 Air volume flow 1310 Fuel Liquid gas Fuel/gas type Cat I Energy efficiency ratio Unit connection pressure Unit connection value kg/h 0.78 - 2.0...
  • Page 22: Electrical Wiring Diagram

    REMKO PGM (E) series Electrical wiring diagram PE L1 Legend: = Terminal block = Operating switch = Fan motor STB = Safety temperature limiter = Solenoid valve = Thermocouple = Piezo igniter TMV = Safety pilot (thermo-electric gas valve) = Ignition electrode...
