DMX Controlled

1. The device will start test-mode.
2. Press MODE button to enter mode setting.
3. Switch to System Mode, then press the Set Up-button.
4. Enter the amount of tubes you are using.
5. For DMX Controlled you have to use DMX Channel: 1-65535, then press the Set Up-button again.
6. The LCD now shows "Set Address
or YES (=Up-Button) to store your choice.
7. Now your unit is DMX-Controlled. You will find all the pre-programmed scenes below.
Channel 1
0-28
29-57
58-86
87-115
116-144
145-173
174-202
203-231
232-255
Channel 2
0-12
13-25
26-38
39-51
52-64
65-77
78-90
91-103
104-116
117-129
130-142
143-155
156-168
169-181
182-194
195-207
208-220
221-233
234-246
247-255
Channel 3
0-255
To select programs via DMX Mode you have to make combinations of CHANNEL 2 and CHANNEL 1.
YES"; press SETUP-Button (=NO) to keep your previous settings,
Black-out
Static RED
Static GREEN
Static YELLOW
Static BLUE
Static PURPLE
Static CYAN
Static WHITE
Color Change
Slow Flow 1
Slow Flow 2
Roll Chase 1
Roll Chase 2
Multi Color
Fast Flow 1
Fast Flow 2
2 Color Chase
2 Color Flow
Color Fade
B+W Flow
R+G Flow
G+B Flow
R+B Flow
R+G Chase
R+B Chase
R+W Chase
B+G Chase
W+G Chase
Rainbow Chase
Strobe Setting Variable from OFF to 20Hz (0-255).
255=ON
