Dmx-Controlled - SHOWTEC LED Tube Basic Square Product Manual

DMX Controlled
1. Turn the power switch on. Press MODE button and select DMX Mode.
2. Then press the Set Up-button; the display shows the current DMX starting address.
3. For DMX Controlled you have to use DMX Channel: 1-255.
4. Then press the Set Up-button again to confirm your setting.
5. Now your unit is DMX-Controlled. You will find all the pre-programmed scenes below.
Channel 1 - Colors
0-5 Blackout
6-11 Red
12-17 Green
18-23 Yellow
24-29 Blue
30-35 Purple
36-41 Cyan
42-47 White
48-53 Fast Change
54-59 Slow Flow 1
60-65 Fast Flow 1
66-71 Fast Flow 2
72-77 Black Run 1
78-83 Roll Chase
84-89 Roll Color
90-95 Color 1/4
96-101 Color1 1/4
102-107 Color 1/2
108-113 Color Flash
114-119 B & W Flow
120-125 R & G Flow
126-131 G & B Flow
132-137 R & B Flow
138-143 R & G Chase 1
144-149 R & G Chase 2
150-155 R & B Chase 1
156-161 R & B Chase 2
162-167 R & W Chase 1
168-173 R & W Chase 2
174-179 B & G Chase 1
180-185 B & G Chase 2
186-191 W & G Chase 1
192-197 W & G Chase 2
198-203 Rainbow Chase 1
204-209 Rainbow Chase 2
210-215 Rainbow Chase 3
216-221 Rainbow Chase 4
222-255 Rainbow Chase 8
Channel 2 – Setting of Speed, Flash or Color combinations
0-255 Speed
Channel 3 –Time Interval
0-255 Adjust the Time Interval from 0-255 (0-100%).
Channel 4 – Strobe
0-255 Adjust the Strobe from 0-255.
