  • Page 1 Shogun Pro-500 ORDERCODE 32041...

  • Page 2: Table Of Contents

    Trinity 500mW Semi-Pro Projector Neo-Laser International CONTENTS PAGE 1. Introduction……………………………….…..3 2. AC Power…………………………………..5 3. Installation………………………………….…8 4. CypherLiteUSB Operating Instructions ...….9 5. Sound Active ……………………...……..…12 6. ILDA DB-25 Operation…..…………….…….12 7. DMX Control..........15 8. Auto-Play Mode...........18 9. Troubleshooting..………………………….19 10. Technical Specifications………………...…..20 The following is a guide to installing your new Trinity 500mW Semi-Pro projector.

  • Page 3: Introduction

    Trinity 500mW Semi-Pro Projector Neo-Laser International NTRODUCTION Thank you for purchasing this laser product. You can be assured that you have made an investment into the highest quality laser products available today. The development team at Neo-Laser has designed this product. Neo- Laser is the subsidiary of Neo-Neon Holdings an ISO-9001 certified company whose manufacturing facilities are located in the P.R.
  • Page 4 Trinity 500mW Semi-Pro Projector Neo-Laser International To protect yourself and others from electric shock • Disconnect the fixture from AC power before removing or installing the projector, fuses, or any part service. • Always ground (earth) the projector electrically. Failure to do so may damage your projector.

  • Page 5: Ac Power

    Trinity 500mW Semi-Pro Projector Neo-Laser International 4UNPACKING The packing material is carefully designed to protect the projector during shipment - always use it to transport the projector. The Projector comes with: • One 5m DB25 cable • Two (2) Keys, please record the number on the fob and retain for future reference.
  • Page 6 Trinity 500mW Semi-Pro Projector Neo-Laser International How to Earth your power supply Warning! The power supply used to power the projector requires earthed (grounded) power mains. All power cables used in the installation of the projector and the computer or DMX console should have three pins.
  • Page 7 Trinity 500mW Semi-Pro Projector Neo-Laser International Never connect the projector or computer to a dimmer or relay- type system. To apply power Warning! The power cables must be undamaged and rated for the electrical requirements of all connected devices. Important! Powering through a dimmer system will damage the projector and computer.

  • Page 8: Installation

    Trinity 500mW Semi-Pro Projector Neo-Laser International INSTALLATION LOCATION AND ORIENTATION For safe operation, install the Projector and Computer in a location where: - • It is at least 0.3 meters (12 inches) away from illuminated surfaces and combustible materials. • It is not easily touched or bumped.

  • Page 9: Cypherliteusb Operating Instructions

    Trinity 500mW Semi-Pro Projector Neo-Laser International USB Operating Instructions CAUTION: Use of controls, adjustments, or performance of procedures other than what is specified herein may result in hazardous radiation exposure, which can result in severe eye damage and or physical injury. This projector is designed to operate using IDLA standard Signal (DB25), USB or DMX-512.
  • Page 10 Trinity 500mW Semi-Pro Projector Neo-Laser International 6. In the next screen click the “Browse” button and find the folder titled “USB Driver”, select that folder and click “OK” The wizard will then load the necessary files and you will see the PC recognize the Flashback3 board in the projector.
  • Page 11 Trinity 500mW Semi-Pro Projector Neo-Laser International 12. You can now click on any cue and it will play instantly. 13. You can change the size, speed, position, color, visible points, fade up and down, etc. all from this menu. All of these feature are also available via DMX-512.

  • Page 12: Sound Active

    Trinity 500mW Semi-Pro Projector Neo-Laser International Sound Active Mode 1. Upload the sound active workspace to the Flashback3. 2. Play your audio at the level you expect the laser projector to respond to. 3. Adjust the sound sensitivity knob on the back of the unit until you see Laser light.
  • Page 13 Trinity 500mW Semi-Pro Projector Neo-Laser International Compliance Statement Compliance Statement Your new TRINITY 500mW Semi-Pro Projector has been designed to comply with FDA and IEC Standards for it classification. The TRINITY 500mW Semi-Projector is a Class IIIB laser product. Laser Safety and Compliance Information This product is manufactured to comply with the IEC 60925-1 and in accordance with U.S.
  • Page 14 Trinity 500mW Semi-Pro Projector Neo-Laser International A Combo label with the Product Model Number, Serial Number, Date of Manufacture, Laser Light Warning Label, Warranty Void Label and Interlocked Housing Label Proper Usage Safety Compliance Information This projector has been designed to be hung from a truss, ceiling or on a wall. It is recommended that, for safety purposes, your projector be mounted using either a suitable hanging clamp or bolted to the surface as instructed in this manual.

  • Page 15: Dmx Control

    Trinity 500mW Semi-Pro Projector Neo-Laser International DMX Control Control features Your projector’s DMX feature is capable of being controlled from a DMX-512 controller. The projector utilizes the effects on your SmartMedia Card. To learn more about CypherLiteUSB, please refer to the CypherLiteUSB Manual on the Software Disc. Connecting your projector to a DMX-512 Controller DMX-512 uses a three-pin cable similar to XLR or Microphone leads.
  • Page 16 Trinity 500mW Semi-Pro Projector Neo-Laser International Dip Switch Settings This projector uses dip switches to assign the desired DMX address. DMX-512 is a simple to use control protocol that allows you to control up to 512 channels at any one time. The NLSP250LDRGB Projector uses 14 Channels to control its functions.
  • Page 17 Trinity 500mW Semi-Pro Projector Neo-Laser International © Neo-Laser, Guang Dong China All rights reserved. No part of this manual may be reproduced, in any form, Without the express permission, in writing from Neo–Neon LTD GUANGDONG, China Printed in China 2005...

  • Page 18: Auto-Play Mode

    Trinity 500mW Semi-Pro Projector Neo-Laser International AUTO-PLAY Using the CypherLiteUSB software you can also set the unit up to run a cue as soon as it powers up. This may be useful in settings where the projector is used for advertisement or to project logos and does not require an operator.

  • Page 19: Troubleshooting

    Trinity 500mW Semi-Pro Projector Neo-Laser International Troubleshooting Problem Remedy Laser does not light. Power On? Key on? DB-9 Interlock on? Volume Knob (sound active mode only) ? Smart Media Card present with the gold pins facing down? Image appears either too wide or too thin. Adjust the “X”...

  • Page 20: Technical Specifications

    Trinity 500mW Semi-Pro Projector Neo-Laser International Technical Specifications Model: TRINITY 500mW Semi-Pro Series Projector Laser Type: LD & DPSS Laser Life: 6,000 to >10,000 Hours Output Type: CW Cooling: TEC Thermal Electronically Cooled Color: 300mW 650nm Red; 150mW 532nm Green; 100mW 473nm Blue Output: 500mW RGB Modulation: Analog AC Power: 80-250V AC Self Switching...
