4
Plug&Charge identification method is set by factory default and enables the user to start
a charging transaction without an identification. This configuration could be adequate for
equipment placed in private areas where only reliable users have access.
Standby
A
When the Charge Point LED beacon light is green in a fade-in/
fade-out effect, it means that the unit is available and ready to
start a charge transaction.
B

Start charging

To start the charge transaction, plug the cable that connects the vehicle to the Charge
Point.

Charging

C
Once the charge transaction is started, the LED beacon light will
turn blue in a fade-in/fade-out effect.

Charge stopped

D
In some cases the charge transaction can be stopped due to
different causes such as:
16
Wallbox eNext
Instruction manual
