Specifications - Altronix Trove1V1R Installation Manual

Altronix Trove1V1R rack mount access & power integration solution accommodates various combinations of HID VertX
power supplies and accessories for access systems.
Agency Listings:
• CE European Conformity.
Trove1V1R
Trove1R rack mount enclosure with
TV1R Altronix/HID VertX
®
• 16 Gauge black enclosure with ample knockouts for convenient access.
• Includes: tamper switch, cam lock and mounting hardware.
Modular 2U standard EIA 19" drawer with extendable slides up to 48".
• Dimensions (H x W x D): 3.25" x 19.0" x 26.5"
(82.6mm x 482.6mm x 673.1mm).
• Up to two (2) eFlow4NB, eFlow6NB, eFlow102NB, eFlow104NB, ACMS8(CB) or ACM8(CB).
• Up to three (3) ACM4(CB), MOM5, PD4UL(CB), PD8UL(CB), PDS8(CB), or VR6.
V100, V200, V300, V1000 or V2000
• Up to six (6)
Assembling and Attaching Z Bracket Wire Management Accessory (included):
Altronix Trove Rack enclosures include Z Bracket, a convenient and reliable wire management accessory.
Hardware (included):
Ten (10) bolts and
1. Carefully unpack Z Bracket. Do not discard hardware (included)
(Fig. 1, pg. 2).
2. Attach arms to each other using bolts and
lock nuts (Fig. 1a, pg. 2).
3. Attach the hinge brackets to the ends of
arms using bolts and nuts positioning
them as shown on Fig. 1b, pg. 2.
4. Make sure that all nuts are tightened.
5. Attach the hinge bracket on the longer side of Z Bracket to the adjustable slide using bolts and lock nuts (included) (Fig. 2, 2a, pg. 2).
6. Attach the hinge bracket on the shorter side of Z Bracket to the rear of the rack enclosure using bolts (included).
Fig. 2
- 2 -
backplane.
Backplane Accommodates a Combination of the Following:
.
eight (8) lock nuts.
Overview:

Specifications:

TV1R
Altronix/HID VertX
• 16 Gauge backplane.
• Dimensions (H x W x D): 18.5" x 15.25" x 0.3125"
(469.9mm x 387.4mm x 7.9mm).
Optional Accessories:
RE2:
• Rack Mount Battery Enclosure accommodates up to four (4)
12VDC/7AH batteries
WM5, WM25, WM100:
•
LC3:
• 6 ft. three-wire line cord.
Fig. 1a
boards with or without Altronix
®
® backplane.
Magnetic Cable Tie Mounts (5, 25, 100 counts).
Fig. 1
Two (2)
Fig. 1b
Fig. 2a
Trove1V1R
