Altronix Trove1V1, Trove2V2 and Trove3V3 accommodate various combinations of HID VertX
and sub-assemblies for access systems.
• UL 294 - 6th edition: Line Security I, Destructive Attack I, Endurance IV, Stand-by Power II (Stand-by Power Level I if no battery is supplied).
• This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme á la norme NMB-003 du Canada.
• CE European Conformity.
Trove1V1
Trove1 enclosure with TV1 Altronix/HID VertX
• 16 Gauge enclosure with ample knockouts for convenient access.
• Includes: tamper switch, cam lock, lock nuts and
mounting hardware.
• Enclosure Dimensions (H x W x D):
18" x 14.5" x 4.625" (457mm x 368mm x 118mm).
TV1
Altronix/VertX
backplane.
®
• 16 Gauge backplane.
• Includes mounting hardware.
• Dimensions (H x W x D):
16.625" x 12.5" x 0.3125" (422.3mm x 317.5mm x 7.9mm).
See TV1 Sub-Assembly Position Chart on Pg. 3 for the list of
compatible sub-assemblies.
Trove2V2
Trove2 enclosure with TV2 Altronix/VertX
• 16 Gauge enclosure with ample knockouts for convenient access.
• Includes: tamper switch, cam lock, lock nuts and
mounting hardware.
• Enclosure Dimensions (H x W x D):
27.25" x 21.75" x 6.5" (692.2mm x 552.5mm x 165.1mm).
TV2
Altronix/HID VertX
backplane only.
®
• 16 Gauge backplane.
• Includes: lock nuts and mounting hardware.
• Dimensions (H x W x D):
25.375" x 19.375" x 0.3125" (644.5mm x 492.1mm x 7.9mm).
See TV2 Sub-Assembly Position Charts on Pgs. 5, 7 for the list of
compatible sub-assemblies.
Hardware:
Snap On Spacer
- 2 -
Overview:
Agency Listings:
Specifications:
backplane.
®
backplane.
®
Metal or Nylon Spacer
boards with or without Altronix power supplies
®
TMV2 - Optional Door Backplane
• Fits Altronix Trove2 and Trove3 enclosure door.
• Dimensions (H x W x D):
23.75" x 18.125" x 0.3125" (603.3mm x 460.4mm x 7.9mm).
See TMV2 Sub-Assembly Position Chart on Pg. 8 for the list of
compatible sub-assemblies.
Trove3V3
Trove3 enclosure with TV3 Altronix/VertX
• 16 Gauge enclosure with ample knockouts for convenient access.
• Includes: two (2) tamper switches, cam lock, lock nuts and
mounting hardware.
• Enclosure Dimensions (H x W x D):
36.12" x 30.125" x 7.06" (917.5mm x 768.1mm x 179.3mm).
TV3
Altronix/HID VertX
backplane only.
®
• 16 Gauge backplane.
• Includes: lock nuts and mounting hardware.
• Dimensions (H x W x D): 34" x 28" x 0.3125"
(863.6mm x 711.2mm x 7.9mm).
See TV3 Sub-Assembly Position Charts on Pgs. 9, 11 for the list
of compatible sub-assemblies.
Battery Backup:
• Trove1 enclosure accommodates up to
two (2) 12VDC/7AH batteries.
• Trove2 enclosure accommodates up to
two (2) 12VDC/12AH batteries.
• Trove3 enclosure accommodates up to
four (4) 12VDC/12AH batteries.
7/8" Pan Head Screw
backplane.
®
5/16" Pan Head Screw
Trove / HID VertX Installation Guide
Lock Nut
