Altronix Trove1V1R Installation Manual page 8

2.4"
61mm
26.5"
673.1mm
3.25"
82.3mm
Altronix is not responsible for any typographical errors.
140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056
web site: www.altronix.com | e-mail: info@altronix.com | Made in U.S.A.
IITrove1V1R
- 8 -
Trove1R Enclosure Dimensions (H x W x D):
3.25" x 19.0" x 26.5" (82.6mm x 482.6mm x 673.1mm). Shown with Z Bracket attached.
1" (25.4mm)
4.57"
116.1mm
19" (482.6mm)
11.175" (283.8mm)
0.55" (14mm)
R 1.27" (32.3mm)
L12R
0.1"
2.5mm
3.62"
92mm
1.5"
38.1mm
MEMBER
Trove1V1R
