Access & Power Integration
Trove1M1R
- Trove rack enclosure with Altronix/Mercury backplane (TM1R)
Installation Guide
More than just power.™
All registered trademarks are property of their respective owners.
Rev. TMR112818
Installing Company: _____________________ Service Rep. Name: __________________________________________
Address: ________________________________________________________ Phone #: _________________________
Advertisement
Table of Contents
Related Manuals for Altronix Trove1M1R
Summary of Contents for Altronix Trove1M1R
- Page 1 Access & Power Integration Trove1M1R - Trove rack enclosure with Altronix/Mercury backplane (TM1R) Installation Guide More than just power.™ All registered trademarks are property of their respective owners. Rev. TMR112818 Installing Company: _____________________ Service Rep. Name: __________________________________________ Address: ________________________________________________________ Phone #: _________________________...
- Page 2 Overview: Altronix Trove1M1R rack mount access & power integration solution accommodates various combinations of Mercury boards with or without Altronix power supplies and accessories for access systems. Specifications: Agency Listings: TM1R • CE European Conformity. Altronix/Mercury backplane. Trove1M1R • 16 Gauge backplane.
- Page 3 Assembling and Attaching Z Bracket Wire Management Accessory (included): Altronix Trove Rack enclosures include Z Bracket, a convenient and reliable wire management accessory. 1. Carefully unpack Z Bracket. Do not discard hardware (included) (Fig. 1, pg. 3). 2. Attach arms to each other using bolts and lock nuts (Fig. 1a, pg. 3).
- Page 4 1. Remove backplane from enclosure prior to installing into rack cabinet (do not discard hardware). 2. In order to mount included UL Listed tamper switch (Altronix Model TS112 or equivalent), turn the enclosure upside down. Punch out the knockout in designated location, on the back of the unit, from outside of the drawer (Fig. 3, pg. 4).
- Page 5 TM1R: Configuration of Altronix Power Supply and/or Sub-Assembly Boards 1. Fasten spacers onto metal pems configuration (A) or (B) of backplane depending on the power supply and/or Sub-Assembly (Fig. 4, pg. 5). 2. Position access controller module over corresponding spacers and fasten screws into spacers (Fig. 4a, pg. 5).
- Page 6 3. Mount backplane to enclosure with hardware. Access Controller Position Chart for the Following Models: Mercury Access Controller Pem Mounting EP1502, MR52, MR16IN, MR16OUT EP2500, MUX8 EP1501, MR51e MR50 Fig. 5 Fig. 5a Pan Head Screw Power Supply or Sub-Assembly Spacer Backplane - 6 - Trove1M1R...
- Page 7 TM1R Enclosure Dimensions (H x W x D): 18.5” x 15.25” x 0.3125” (469.9mm x 387.4mm x 7.9mm) 15.25” (387.4mm) 18.5” 469.9mm Trove1M1R - 7 -...
- Page 8 3.25” 82.3mm Altronix is not responsible for any typographical errors. 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 web site: www.altronix.com | e-mail: info@altronix.com | Made in U.S.A. IITrove1M1R H21T MEMBER - 8 -...
