Door Swing Dimensions - Jenn-Air JS42NXFXDE Install

FRONT VIEW
Width dimensions were measured from hinge to
hinge.
When leveling legs are fully extended to 1¹⁄₄" (3.2 cm)
below rollers, add 1¹⁄₄" (3.2 cm) to the height
dimensions.
A
(see chart following)
MODEL WIDTH A (HINGE EDGE TO HINGE EDGE)
42
48
10
*83 ⁄ "
(211.8 cm)
41³⁄₄" (106 cm)
47³⁄₄" (121.3 cm)

DOOR SWING DIMENSIONS

The location must permit both doors to open to a
minimum of 90°. Allow 4¹⁄₂" (11.4 cm) minimum space
between the side of the refrigerator and a corner wall.
NOTE : More clearance may be required if you are using
wood overlay panels, custom handles, or extended
handles.
A B
90˚
110˚
MODEL A
40³⁄₄"
42
(103.5 cm) (101.0 cm)
43¹⁄₄"
48
(109.9 cm) (106.7 cm)
90˚
110˚
B C
39³⁄₄" 45³⁄₈"
(115.3 cm) (118.8 cm)
42" 48⁵⁄₈"
(123.5 cm) (127.6 cm)
C D
D
46³⁄₄"
50¹⁄₄"
