UNPACK THE REFRIGERATOR

WARNING
Tip Over Hazard
Refrigerator is top heavy and tips easily when not
completely installed.
Keep doors taped closed until refrigerator is
completely installed.
Use two or more people to move and install
refrigerator.
Failure to do so can result in death or serious injury.
IMPORTANT :
Do not remove the film covering until the refrigerator
is in its operating location.
All four leveling legs must contact the floor to support
and stabilize the full weight of the refrigerator.
Keep the cardboard shipping piece or plywood under
the refrigerator until it is installed in the operating
location.
1.
Remove and save the literature package and
hardware kit located inside the refrigerator. Remove
and save the literature, grille, and trim taped to the
outside of the refrigerator.
NOTE : Do not remove tape and door bracing until
the refrigerator is in its final location.

MOVE THE REFRIGERATOR INTO HOUSE

WARNING
Tip Over Hazard
Refrigerator is top heavy and tips easily when not
completely installed.
Keep doors taped closed until refrigerator is
completely installed.
Use two or more people to move and install
refrigerator.
Failure to do so can result in death or serious injury.
12

INSTALLATION INSTRUCTIONS

1.
Place an appliance dolly under the left side of the
refrigerator as shown. Place the corner posts from
the packing materials over the trims as appropriate.
Slowly tighten the strap.
2.
Place pieces of the shipping carton on the floor when
rolling the dolly and refrigerator into the house. Move
the refrigerator close to the built-in opening.
3.
Place top of cardboard carton or plywood under
refrigerator. Stand the refrigerator up. First, place the
left bottom edge of
the refrigerator upright and then lower the right-
hand side of the refrigerator to the floor.
4.
Reassemble the trim and top grille after the dolly has
been removed from the refrigerator.

INSTALL ANTI-TIP BOARDS

IMPORTANT :
If a solid soffit is not available, anti-tip boards must be
installed.
It is recommended that boards be installed before
the refrigerator is installed.
Boards must be long enough to fully cover the width
of the compressor cover.
Place the boards so that the bottom surfaces of the
boards are 84" (213 cm) from the floor.
During installation, raise the refrigerator up until
the top of the refrigerator is making contact with
the bottom of the anti-tip boards. Do not crush the
compressor cover when raising the rear leveling legs.
NOTE : The foam gasket, on top of the compressor
cover, will compress to fit under the anti-tip board(s).
There is no need to trim the gasket.
the refrigerator on the floor, stand
